ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
21
1 Side Burner Assembly
1 Side Burner Knob
2 Grill Body Supports
1 Left Side Cart Panel
1 Front Cart Panel
1 Right Side Cart Panel
4 Locking Casters
1 Bottom Cart Shelf
PARTS LIST:
1 Hood
1 Warming Rack
2 Cooking Grills
3 Heat Distribution Plates
3 Stainless Steel Tube Burners
1 Grease Tray
1 Grill Body Assembly
1 Grease Cup
1 Side Burner Grate
3 Control Knobs
1 Brass Burner Ring
1 Side Table
1 Electronic Igniter Button
1 Electronic Igniter Spring
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
22
21
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this Brinkmann Augusta Grill:
• Flathead Screwdriver (included)
• Hex Nut Wrench (included)
