Step 23

Hang the charcoal grate inside the

charcoal grill body.

Step 24

Place cooking grates on support ribs

directly above charcoal grate.

Step 25

Place the heat distribution plates on lower

level of grill body assembly directly above

burners.

Step 26

Place cooking grates on support ribs

directly above heat distribution plates.

Charcoal Grate

Cooking Grates

Heat Distribution

Plates

Cooking Grates
