ROTISSERIE ASSEMBLY INSTRUCTIONS:
Step 1
Open grill hood and remove
cooking grills.
Step 2
Attach rotisserie bracket A on the
left hand side of the grill using two
M6 x 10 mm bolts (black) and two
M6 nuts.
Step 3
Slide rotisserie motor onto the
rotisserie bracket A.
Step 4
Attach rotisserie bracket B inside
the right hand side of the grill
using two M6 x 10 mm bolts
(black) and M6 nuts.
Step 5
Slide rotisserie forks onto spit rod.
Insert spit rod into rotisserie motor.
Step 6
Align spit rod groove with right
side bracket as illustrated.
Right Side
Rotisserie Bracket
Spit Rod
Groove
35
