ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR SMOKER.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
(Proof of purchase will be required.)
3
We recommend two people work together
when assembling this unit.
The following tools are required to assemble
the Smoke’N Pit Pitmaster:
• Hammer
• Pliers
• Phillips & Flathead Screwdriver
•
7
/
16
" Wrench or Adjustable Wrench
• Small Block of Wood
Parts Bag Contains:
1 Chrome push plug (Not furnished if
temp. gauge is included)
1 Zinc push nut (Smokestack damper)
2 Plastic wheel push caps
2 Plastic leg end caps
4 4" x 12" Rear grill support bolts
4 10-24 Screws & nuts
(bolts handle halves to brackets)
21 4" Hex nuts
5 4" Lock washers
(4 for handles, 1 for butterfly damper)
10 4" x w" Bolts
14 4" Flat washers
8 2" Self tapping screws
2
7
/
16
" Flat washers (wheels)
1 4" Indented lock nut
(for ash-guard shield)
12
3
/
16
" x 12" Carriage bolts & nuts
1
3
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
PARTS LIST:
1 Cooking chamber
1 Air vent butterfly damper
1 Smokestack
1 Smokestack damper
1 Ash-guard shield
2 Cooking grills
2 Charcoal grates
2 Metal brackets for handle
4 Wooden handle halves
1 Wire rack (for wood)
4 Front grill support brackets
4 Metal shelf brackets
3 Wooden shelf slats
1 Leg brace with L-bracket
1 Leg brace
2 Legs
2 Legs w/wheel axle
2 Wheels
1
3
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
(Butterfly damper
installs inside of
cooking chamber)
