BRINKS Push Pull Rotate - Page 2

S5
S1 (2)
S2 (2)
B
S4
S3 (2)
C
K
J
I
G
S6
A
D
H
T1
T2 (2)
E
F
YOUR HANDLESET MAY OR MAY
NOT BE SUPPLIED WITH A
DEADBOLT OR DEADBOLT
EXTERIOR. IF IT IS, PLEASE SEE
SEPARATE INSTRUCTIONS FOR
DOOR PREPARATION AND
INSTALLATION OF THE DEADBOLT.
SCREWS
S1
S2
S3
Latch Screws (2)
Strike Plate Screws (2)
Main Lock Body Machine Screws (2)
Installed in Lever
S4
S5
S6
Lower Handle Machine Screw (1)
Lever Retention Screw (1) & Lockwasher (1)
Handle Pivot Bolt (with O-Ring) (1)
TOOLS
T1 - Hex Wrench
T2 Hex Adaptor (2)
QUESTIONS?
CALL 1-800-562-5625
FOR H E LP.
