DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS.

Contents of this page can be found in: Hardware Bag Z-1216-A
HARDWARE IDENTIFIER
Illustrations on this page
are to scale for faster

during assembly.
Bolt:
Hex Head
1/2 x 1-1/2”
 . . . . . . . . . .
1M1624P
28
Bolt:
Hex Head
1/2 x 1-3/4”
 . . . . . . . .
1M1628P
29

1/2 x 2"
 . . . . . . . .
15M1632P
35
1
Nut: Hex
Locking, 5/16” -18
 . . . . . . . . . . . . . . . . . . .
B-1674P
39
Nut: Hex
 . . . . . . . . .
30M2000P
3
Nut: Hex
Locking, 5/8”
 . . . . . . . . . . . . . . . . .
B-1678P
Spacer
5/8" ID x 1/2"
 . . . . . . . . . . . .
P-597
26
Trunnion
 . . . . . . . . . .
P-598-01
27
Washer;
Flat, 5/16”
 . . . . . . . . . . . .
45M1111P
42
Washer;
Flat, 5/8”
 . . . . . . .
45M2121P
45
Washer;
Flat, 1/2”
 . . . . . . . .
45M1717P
44
4 L-1043-3-BEnglish Manual
