DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS.
Hardware Bag Z-1216-C
HARDWARE IDENTIFIER
Illustrations on this page
are to scale for faster
during assembly.
2 Nut; Hex Lock, 1/2"-13 3
7 Spacer 1
14 1
17 1
30 Bolt; Hex Head, 5/8-11 x 2" 2
31 Bolt; Carriage, 5/16 x 3/4" 3
32 Bolt; Carriage, 1/2" x 1-1/2" 1
33 15M1216-R 2
36 Nut; Reg Hex, 3/8"-16 2
38 Nut; Hex, 1/2"-13 2
40 Nut; Jam Hex, 5/8"-11 2
41 Nut; Square Head, 1/2"-13 1
46 1
Hardware Bag Z-1216-B
6 Coulter Axle; Bolt, 5/8 x 4" 1
23 U-Bolt 1
24 1
Hardware Bag Z-1216-C
Ref # Part # Description Qty
1 Nut; Lock, 5/16"-18 3
3 Nut; Lock, 5/8"-11 2
26 Spacer; Coulter, 5/8" ID x 1/2" 2
27 1
28 Bolt; Hex Head, 1/2" x 1-1/2" 2
29 Bolt; Hex Head, 1/2" x 1-3/4" 2
35 1
39 Nut; Hex, 5/8"-11 2
42 Washer; Flat, 5/16" 3
44 Washer; Flat, 1/2" 1
45 Washer; Flat, 5/8" 2
Hardware Bag Z-1216-A
23
U-Bolt
P-386P
6
P-172P
24
P-387-01
6 L-1043-3-BEnglish Manual
