HIGHPOINT User Guide
• To replace, press the lower anchor release button on the child’s
left side of the booster base and then pull the lower connector
adjuster strap until the connectors retract into the base� Ensure
the straps are not twisted�
NOTE: The lower connectors may need to be rotated so they
retract into the slots with the bottom side facing down.
Attaching and Removing Lower Connector from Vehicle Lower Anchor
• To attach, remove the lower connector from the storage slot
and firmly push down onto the vehicle lower anchor until a click
is heard�
• To remove, push the lower connector release button on the
child’s left side of the booster seat to loosen connector strap
(see page 18)� Then press and hold the red lower connector
release buttons and pull the connectors from the vehicle
lower anchors�
