Britax MINI - Attaching the Arm Bar; Stroller Operation; Operating the Brakes; Front Wheel Swivel Lock

17 16
Operating the Brake Front Wheel Swivel Lock Adjusting the Backrest
WARNINGS:
ALWAYS APPLY THE BRAKES WHEN THE STROLLER
IS STATIONARY.
Stroller Assembly
WHEN A CHILD IS IN THE STROLLER, KEEP THE
ARM BAR ATTACHED AT ALL TIMES.
A.
Align the pins on
each side of the
arm bar with the
arm bar sockets
on the seat. Press
and hold the button
underneath the arm
bar sockets then
slide the arm bar
pins into the sockets
until It is locked.
Please ensure It is
locked.
B.
To remove the
arm bar, press and
hold the button
underneath the
arm bar and pull
the arm bar out.
Rotate the arm bar
for easy access.
A.
To engage the
brake, step on
the red brake
pedal until you
hear a ‘click’. The
indicator window
will change to
red.
B.
To disengage
the brake, step
on the red brake
pedal until you
hear a ‘click’. The
indicator window
will change to
green.
Stroller Operation
PLEASE NOTE: Always lock the front wheels
when strolling over uneven terrain or rough
surfaces as this will minimise wheel wobble.
The swivel wheels can only be locked when
the wheels are facing forward.
A.
To lock, push the
swivel lock down
on both wheels.
B.
To unlock, push
the swivel lock up
on both wheels.
Stroller Operation
WARNINGS:
• THE UPRIGHT POSITIONS ARE NOT SUITABLE FOR
USE WITH CHILDREN LESS THAN 6 MONTHS OLD.
• THE LOWEST RECLINE POSITION SHOULD BE USED
TO TRANSPORT BABIES. THE BACKREST CAN BE
ADJUSTED TO A MORE UPRIGHT POSITION AS THE
CHILD GROWS OLDER AND IS ABLE TO SUPPORT
ITS HEAD WITHOUT ASSISTANCE.
TIP: If the child is sitting in the seat, support
the backrest as it reclines. If you have difculty
adjusting the backrest you may need to
remove the child from the seat to allow you to
raise or lower the backrest with ease.
Lift the recline
lever on the
back of the seat
to adjust to the
desired position.
TIP: There are
ve backrest
positions.
CAUTION
A A
A
B B
B
Attaching the Arm Bar
