45
The child restraint is assembled with the
harness in the inner loop.
‐ Inner Loop: Maximum 11 lbs (5 kg).
‐ Outer Loop: 4 - 30 lbs (1.8kg - 13.6kg)
IMPORTANT: The harness straps should be
located in the closest harness height position
below the child’s shoulders.
IMPORTANT: Ensure the harness straps are
fully secured on the harness yoke.
Inner Loop
Outer Loop
1. Loosen the child restraint harness by
pressing the harness adjuster release
lever and pulling both harness straps
forward.
1
Child Restraint Functions
Adjusting the Harness
