Brivis contour Service Manual

Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
10
Brivis Technical Data
Type: Technical Data Base Date Updated: 13/01/2004
Category: Specification Sheet - Cooler
Subject: Contour L 13
Sizing Guide Reference Figure 1000 - 1450
Cabinet detail
Width 1100 mm
Height front 720 mm
Height back 400 mm
Length 1100 mm
Dry Weight 48.5 kg
Wet Weight 65.2 kg
Filter Pad Details Water Treatment Unit
Quantity 4 Type WE-1
Thickness 60 mm Rating 240 V / 50 Hz 10 Watt
Type CELDEK 5090 Amps 0.12
Air/Gas Flow Rate 1 L/minute minimum flow
Duct Outlet Size
Width 550 mm
Length 550 mm
Pump / Water Distribution
Motor Pump Type ASKOLL M115
Type 240 V - 1 ph Pump Rating 240 V / 0.2 Amps
Model FASCO Pump Capacity 20 L/minute
855BNVA-A12 Winding Resistance 206 Ohms (+/- 8% @ 20
o
C)
Watts 315 Overflow size 40 mm
Amps 2.4 Waste Outlet Size 40 mm
R.P.M. 1400 Tank Capacity 12 Litres
Capacitor Size 8 uF Distribution Hose Size 20 mm CLEAR HOSE
R.P.M Min Setting 500 Inlet Valve Type ELBI E.V Type 329
R.P.M Max Setting 1250 Inlet Valve Rating 240 V - 0.03 Amps
N-E5 Model Selection Model 2 Inlet Valve Capacity 4 L or 5.5L/minute
Coil Resistance 4.1 kOhm approx. @ 20
o
C
Inlet Valve Size 3/4" BSP (Male) Thread
Fan Impellor ServoSeal Motor
Size 538 mm Dia. Type S.A.I.A
Type BRIVIS 538-6-23 Rating 240 V 50 Hz 0.23 Watt
Blades 6 RPM 500
Blade Angle 23 deg TIP Resistor 470 Ohm
Collet BRIVIS Capacitor 100 nF
Cooler Control Module Wall Controller
N-E5 Networker NC-3
BWC-1 (Electronic)
BWC-2 (Manual)
Water Connection
Flexible Hose Connection with 1/2" BSP (Male) Thread
Drain Connection
40 mm PVC
