Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
27
Motor Circuit Diagram
MOTOR - 750 WATT
DIRECT WIRED
BETTS MODEL - 808855BQVA - A22V
GREEN /YELLOW
BROWN (RUN)
BLUE(COMMON)
START 9.6
MAIN 4.4
EARTH
BLACK (START)
OVERLOAD
CAPACITOR 25 u/F
