Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
26
Motor Circuit Diagram
MOTOR WIRING CIRCUIT DIAGRAM
BETTS 855 BNVA - A12
MOTOR - 315 WATT
DIRECT WIRED
GREEN /YELLOW
BROWN
BLUE(COMMON)
START 38.8
MAIN 10.6
EARTH
BLACK (START)
OVERLOAD
CAPACITOR 8 u/F
