Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
4
Brivis Advance
The Brivis Advance was introduced in 2005 and is designed to take the place of the AD range of
units up to Model AD56. However, the AD76 and AD86 will remain in production.
In essence the Advance is a square shaped Contour/Profile, which sits upon the same base frame
as the Contour/Profiler. So for the purpose of servicing, all the electrical and operational
components are the same and therefore all the information contained in these manuals is relevant.
The BASE is square and sits on a vertical dropper box similar to the AD units, except that the
dropper box should come with outwards turned flange so that the locking brackets on the unit attach
to the dropper box. Like the AD unit, the cooler should be located high enough on the roof to
prevent the back from touching the roof.
The PAD FRAMES are attached in a similar fashion to the Contour and Profile unit. The front and
rear pads can be removed by first lifting the roof assembly, and then lifting the pad assembly out;
the same way the Contour and Profiler work.
The SIDE PAD FRAMES are slightly different and involve the pad frame being rolled into the centre
of the unit and then being raised out. It is important that the pad frame is not forced, as this could
damage the alloy brackets.
The ROOF ASSEMBLY also remains the same as the Profiler/Contour units.
Some standard features differ between the Brivis Profiler, Contour and Advance.
Advance
Motorised winter seal (Servoseal) Yes No No
Counter balanced weather-seal N/A Optional Optional
Motorised dump valve Yes Yes Optional
Aquasave Yes No No
Speed Sensor Yes Yes Yes
Networker compatible Yes Yes Yes
Water sensor Yes Yes Yes
