34
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
(SBCM)
....2 270-102 Cap,monolithic,1000pf 50v
5%KemetC1206C102J5GACTR marked
13 C1,C2,C3,C4,C5,C
6,C7,C8,C9,C10,C
11,C15,C16
....2 270-220 Cap, monolithic chip, 22 pf 50v 5%
KEMET C1206C220J5GACTR
3 C12,C13,C14
....2 310-014 TRANSFORMER, AUDIO, MIDCOM
671-9041 TECATE VFT 950-0394
1 T1
....2 330-018 INDUCTOR, 10 uH, 10% 14 L1,L2,L3,L4,L5,L7,
L8,L9,L11,L12,L13,
L14,L15,L16
....2 330-019 INDUCTOR, 2.5 TURN, HIGH
FREQUENCY SUPPRESSION
2 L6,L10
....2 340-0004 SW,JUMPER PROGRAMMABLE 5 JP1,JP1,JP2,JP1,
JP1
....2 500-162 Screw, 4-40 x 7/16 phillips pan head MS
zinc plated"
2
....2 550-123 Connector, 10 pin header (cut from 550-
162)
1 P1
......3 550-162 Connector, 24 pin break-away (straight)
Molex 26-48-6248
0.417
....2 550-136 Connector, 6 pin Molex header (cut from
550-162)
2 P2,P3
......3 550-162 Connector, 24 pin break-away (straight)
Molex 26-48-6248
0.25
....2 550-170 Connector, D-Sub 15 pin angle 1 J4
....2 550-184 Connector, 1 dual pin header (cut from
550-316)
1 JP2
......3 550-316 HEADER, BREAKAWAY 40x2, 0.1
SPACING"
0.025
....2 550-185 Connector, 5 dual pin header (cut from
550-316) (note)
1 JP1
......3 550-316 HEADER, BREAKAWAY 40x2, 0.1
SPACING"
0.125
....2 550-186 Connector, 3 pin Molex header (cut from
550-162)
1 P4
......3 550-162 Connector, 24 pin break-away (straight)
Molex 26-48-6248
0.125
....2 800-193B PC Board, I/O Filter STL-10 R-10 1 PCB
..1 800-208AC IF Amplifier AR/CR 1
....2 360-032 FILTER, CERAMIC, 10.7MHZ 2 CF1,CF2
....2 800-208A IF AMPLIFIER, AR/CR, GENERIC 1
......3 100-1041 RES,1K OHM,1/4W,1% 1 R5
......3 100-1051 RES,10K OHM,1/4W,1% 2 R19,R20
......3 100-1531 RES,150 OHM,1/4W,1% 2 R1,R2
......3 103-2241 RES,2.21K OHM,1/4W,1%,METAL 3 R6,R8,R15
......3 103-3324 RES,3.32K OHM,1/4W,1%,METAL 2 R3,R9
......3 103-4741 RES,4.75K OHM,1/4W,1%,METAL 1 R16
......3 103-4753 RES,475 OHM,1/4W,1%,METAL 2 R7,R12
......3 145-431 Resistor, 432 ohm 1/4 watt 1% metal film
Mepco SFR25
3 R4,R10,R14
