Broadcast Electronics Marti Electronics SR-30 - Page 45

BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
35
......3 145-470 Resistor, 47.5 ohm 1/4 watt 1% metal
film Mepco SFR25
3 R11,R13,R17
......3 177-5050 RES,TRMR,50K,10%,TOP ADJ 3299Y 1 R18
......3 217-103 CAP,0.1UF 250VDC 5%,POLY FILM 3 C9,C12,C14
......3 217-104 CAPACITOR, .01 UF 50V GMV DISC 10 C1,C2,C3,C4,C5,
C6,C7,C8,C10,C16
......3 219-220 CAPACITOR, ELECTROLYTIC 22uF
RADIAL 35V
1 C13
......3 219-221 CAPACITOR, ELECTROLYTIC 220uF
25V RADIAL
1 C11
......3 255-390C Capacitor, 39pF 5% 200V ceramic
dipped C322C390J2G5CA
1 C15
......3 255-470C CAP, 47pF 5% 200V CERAMIC DIPPED 1 C18
......3 256-131 CAPACITOR, 130 pF 5% 50V NPO
DISC
1 C17
......3 290-521 CAP, VARIABLE, 5-25 pf 1 C19
......3 299-470 CAP, TANTALUM, 4.7 UF 16V 1 C20
......3 350-030 INDUCTOR, 3.0 - 7 UH W/SHIELD CAN
#47271-023
1 L1
......3 350-123 Detector, SNY-074-1919A (235SU1) 1 T1
......3 401-235 INTEGRATED CIRCUIT, SANYO
LA1235
1 IC1
......3 417-1604 SKT,16-PIN,DIP 1 1C1
......3 440-245-1 TRANSISTOR, 2N2857 2 Q1,Q2
......3 550-084 CONNECTOR,PHONO JACK,PCB
MOUNT
1 J1
......3 550-138 Connector, 8 pin Molex header (cut from
550-162)
1 P1
........4 550-162 Connector, 24 pin break-away (straight)
Molex 26-48-6248
0.333
......3 800-208B PC Board, IF 10.7 MHz R Receiver 1 PCB
..1 800-229A AR-10/CR-10 Decode Board 1
....2 100-1041 RES,1K OHM,1/4W,1% 1 R6
....2 100-1051 RES,10K OHM,1/4W,1% 1 R13
....2 101-104 Potentiometer, 100K ohm cermet Bourns
3309P-1-104
1 R1
....2 101-502 POT,5K,SINGLE TURN,HORIZONTAL
PCB MOUNT
1 R16
....2 103-1007 RES,1 MEG OHM,1/4W,1%,METAL 1 R23
....2 103-1062 RES,100K OHM,1/4W,1%,METAL 3 R2,R4,R17
....2 103-1823 RES,182 OHM,1/4W,1%,METAL 1 R15
....2 103-2211 RES,22.1K OHM,1/4W,1%,METAL 1 R8
....2 103-4731 RES,475K OHM,1/4W,1%,METAL 1 R11
....2 103-4741 RES,4.75K OHM,1/4W,1%,METAL 2 R19,R20
....2 104-203 Potentiometer, 20K ohm cermet 64Y203
top adjust
1 R7
....2 145-225 Resistor, 2.21 meg ohm 1/4 watt 1%
metal film (2.21 Meg 1%)
1 R3
....2 145-470 Resistor, 47.5 ohm 1/4 watt 1% metal
film Mepco SFR25
1 R14
....2 145-683 Resistor, 68k ohm 1/4 watt 1% metal film
Mepco SFR25
1 R9
