Broadcast Electronics Marti Electronics SR-30 - Page 47

BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
37
....2 007-3904-050 CAP,.039UF,0805,5%,50V 1 C32
....2 007-3923-050 CAP,CER,3900 PF,1%,50V,1206,SMD 1 C3
....2 007-4704-050 CAP,4700PF,0805,5%,50V 1 C21
....2 007-4724-051 CAP,CER,4700 PF,1%,50V,1206,SMD 2 C4,C5
....2 007-5603-050 CAP,5600PF,0805,5%,50V 2 C25,C37
....2 007-6213-500 CAP,CER,620pF,50V,5%,SMD 2 C50,C51
....2 007-6803-050 CAP,6800PF,0805,5%,50V 1 C20
....2 102-0100 RES,CHIP,10.0 OHMS,1/10W,1%,SMD 1 R28
....2 102-1001 RES,CHIP,1.00K
OHMS,1/10W,1%,SMD
1 R13
....2 102-1002 RES,CHIP,10.0K
OHMS,1/10W,1%,SMD
1 R24
....2 102-1003 RES,CHIP,100K OHMS,1/10W,1%,SMD 4 R11,R23,R25,R27
....2 102-1004 RES,CHIP,1.00M
OHMS,1/10W,1%,SMD
3 R4,R5,R6
....2 102-1214 RES, CHIP, 1.21K OHM, 1/10W, 1% 1 R29
....2 102-1825 RES,CHIP,18.2 K OHM,1/10W,1% 1 R22
....2 102-2001 RES,CHIP,2.00K
OHMS,1/10W,1%,SMD
1 R18
....2 102-2212 RES,CHIP,22.1K
OHMS,1/10W,1%,SMD
1 R26
....2 102-2492 RES,CHIP,24.9K
OHMS,1/10W,1%,SMD
1 R10
....2 102-2741 RES,CHIP,2.74K
OHMS,1/10W,1%,SMD
1 R16
....2 102-3011 RES,CHIP,3.01K
OHMS,1/10W,1%,SMD
2 R17,R30
....2 102-4731 RES,475K OHM,1/10W,1%,SMD 2 R2,R7
....2 102-4751 RES,CHIP,4.75K
OHMS,1/10W,1%,SMD
1 R3
....2 102-4755 RES,CHIP,47.5K OHM,1/10W,1% 1 R12
....2 102-4991 RES,CHIP,49.9 OHMS,1/10W,1%,SMD 1 R1
....2 102-6811 RES,CHIP,6.81K,1/10W,1%,SMD 1 R8
....2 102-7501 RES,7.5K OHMS,1/10W,1%,SMD 2 R14,R15
....2 102-8252 RES,82.5K OHM,1/10W,1% 1 R20
....2 102-9094 RES,CHIP,9.09K OHM,1/10W,1% 1 R21
....2 198-1054 TRMR,10K OHMS,TOP ADJ,SMD (N) 1 R9
....2 198-2024 TRMR,2K OHMS,TOP ADJUST,10
TURN,SMD
1 R19
....2 200-8462 DIODE,ZENER,6.2 VOLT,SMT 1 D1
....2 216-5484 TSTR,JFET,N-
CHANNEL,MMBF5484,SMT
1 Q1
....2 224-1877 IC,HDPHONE AMP,DUAL,LM1877M-
9,14-PIN,SMD
1 U3
....2 340-0004 SW,JUMPER PROGRAMMABLE 4 P1,P2,P3,P4
....2 513-2134 PCB,MACH,BW SELECTABLE AUDIO
BD.
1
....2 550-138 Connector, 8 pin Molex header (cut from
550-162)
2 J5,J6
......3 550-162 Connector, 24 pin break-away (straight)
Molex 26-48-6248
0.333
....2 550-326-16 Connector, Dual Row Header, 16-Pin
(cut from 550-326)
4 J1,J2,J3,J4
