38
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
......3 550-326 CONN, DUAL ROW HEADER, 80-PIN 0.2
....2 DB38003 IC,Lin TLO72 Dual OPAMP SO8 TI
TL072CD
2 U1,U2
..1 943-2133 ASSY,WIRE HARNESS,SR-30/40A
(SBCM)
1
....2 402-0051 TY-RAP, W/FLAG 18
....2 410-1489 LUG,TERM #6 SPADE #16-22 5
....2 417-0096 PLUG,POLARIZING 4
....2 417-0131 CONN,16 PIN 609-1630 ANSLEY 1
....2 417-0142 PIN,.050 DIA 26-22 745254-3 10
....2 417-1500 PLUG,15 PIN 1
....2 417-2026 CONN, POLARIZED WIREMOUNT
SOCKET, .100 PITCH"
1
....2 417-2116 CONN,POLARIZED,WIRE,.1 IN,16-PIN 1
....2 418-0034 PLUG,BNC DUAL CRIMP 1-227079-6 1
....2 418-0609 CONN,25 PIN RIBBON CABLE 1
....2 418-0615 CONN,15-PIN D-TYPE,RIBBON CABLE 1
....2 418-2600 CONN,26-PIN,RIBBON 1
....2 500-128 Eyelet, GS4-4 brass 3
....2 512-020 TERMINAL,NICHIFU TMDN #125-250-
03FA TERMINAL
3
....2 550-122 CONNECTOR, 10 PIN MOLEX
HOUSING 09-50-8100
2
....2 550-133 CONNECTOR, PHONE PLUG 3C1215 3
....2 550-135 Connector, 6 pin Molex housing 09-50-
8060
2
....2 550-137 Connector, 8 pin Molex housing 09-50-
8080
3
....2 550-327 Connector, Crimp Terminal Pin Molex
08-52-0112
54
....2 580-033-1 Coax RG-188A/U Teflon 95% Shield
M4256 TFE Tape Wrap
1.19
....2 580-088 Shielded Wire, 16-C-22-SPJ White/Red
1 Cond. 22/19x34 pvc
13.33
....2 600-0016 CBL,FLAT,16-COND,28GA 1.33
....2 600-0026 CBL,FLAT,26-COND,28GA 2.33
....2 601-1800 WIRE,AWG18 19/30 BLK 1.75
....2 601-2209 WIRE,AWG22,19/34 WHT 45.13
..1 953-2130-002 ASSY,SR-40A FRONT PANEL (SBCM) 1
....2 193-0500 POT,500 OHMS,PCB
MOUNT,LINEAR,HD AUDIO
1 R87
....2 310-0080 METER,MULTI,2 IN,SR-30/SR-40A 1 M1
....2 323-2124 LED INDICATOR,GRN,RECTANGULAR 4 D1,D4,D5,D7
....2 323-3124 IND,LED,YEL 1 D6
....2 340-0168 SWITCH,PUSHWHEEL,SUBMINIATUR
E,PANELMOUNT
9 S4,S5,S6,S7,S8,S9
,S10,S11,S12
....2 417-0311 JACK,SWCRFT #N-112B 3COND. 1 J14
....2 471-5352 PANEL,FRONT,SR40A 1
....2 500-210 Screw,SEMS 4-40x1/4 Phil Pan Head
MS Blk Zinc(external lock)
7
....2 510-005 Polytube, Manhatten#AF155A-20-yel 0.5
