BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
39
....2 510-212 CONTROL KNOBS, #45KNO23 2
....2 530-086 Switch, Dip, 4 Position, Right Angle,
Apem DA04T
1 S1
....2 913-2130-003 ASSY,PCB,SR-30/40A FRONT PANEL
(SBCM)
1
......3 006-1085 CAP,ELECTRO,100 UF,10%,35V,SMD 4 C59,C62,C66,C69
......3 007-1022 CAP,CER,100pF,50V,2%,SMD 1 C72
......3 007-1024 CAP,CER,.001uF,50V,10%,SMD 2 C64,C71
......3 007-1044 CAP,CER,0.1uF,50V,10%,SMD note 28 C1,C2,C3,C4,C5,
C6,C7,C8,C9,C10,
C11,C14,C15,C16,
C17,C18,C19,C20,
C21,C22,C23,C24,
C25,C26,C27,C57,
C77,C78
......3 007-1054 CAP,CER,1uF,50V,10%,SMD 4 C58,C61,C65,C68
......3 007-1512 CAP,CER,15pF,50V,2%,SMD 3 C50,C51,C52
......3 007-1512-500 CAP,CER,150pF,50V,2%,SMD 4 C53,C54,C55,C56
......3 007-3923 CAP,CER,390pF,100V,5%,SMD 2 C63,C70
......3 007-6213-500 CAP,CER,620pF,50V,5%,SMD 1 C48
......3 070-1054 CAP,TANT,1uF,35V,10%,SMD 16 C28,C29,C34,C35,
C36,C37,C38,C39,
C40,C41,C42,C43,
C44,C45,C46,C47
......3 070-2265-L25 CAP,TANT,22 MFD,20%,25V, E
CASE,LOW ESR,SMD
5 C33,C60,C67,C73,
C74
......3 101-1003 RES,CHIP,100.0 K
OHM,1%,1/8W,1206,SMD
1 R99
......3 102-0000 RES,CHIP,0 OHM,0805,SMD 1 R69
......3 102-1000 RES,CHIP,100 OHMS,1/10W,1%,SMD 2 R57,R83
......3 102-1001 RES,CHIP,1.00K
OHMS,1/10W,1%,SMD
14 R33,R34,R35,R36,
R37,R38,R71,R80,
R81,R82,R72,R73,
R76,R78
......3 102-1002 RES,CHIP,10.0K
OHMS,1/10W,1%,SMD
3 R91,R92,R97
......3 102-1003 RES,CHIP,100K OHMS,1/10W,1%,SMD 1 R70
......3 102-1102 RES,CHIP,11.0K
OHMS,1/10W,1%,SMD
1 R77
......3 102-1212 RES,CHIP,12.1K
OHMS,1/10W,1%,SMD
1 R94
......3 102-1582 RES,CHIP,15.8 K, 1/10 W, 1% 1 R95
......3 102-1780 RES,CHIP,178 OHMS,1/10W,1%,SMD 7 R39,R40,R41,R42,
R43,R44,R45
......3 102-2002 RES,CHIP,20.0K
OHMS,1/10W,1%,SMD
1 R86
......3 102-2323 RES,23.2K OHMS,1/10W,1%,SMD 1 R79
......3 102-2431 RES,CHIP,2.43K
OHMS,1/10W,1%,SMD
1 R74
......3 102-3011 RES,CHIP,3.01K
OHMS,1/10W,1%,SMD
1 R64
......3 102-3012 RES,CHIP,30.1K,1/10W,1%,SMD 2 R93,R102
......3 102-4532 RES,CHIP,45.3K
OHMS,1/10W,1%,SMD
2 R84,R88
