44
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
..1 800-207-25 FILTER, ASSEMBLY 25 KHZ 1
....2 215-151C Capacitor, 150pF 5% 200V ceramic
dipped C322C151J2G5CA
1 C1
....2 255-050 CAPACITOR, 5 pF 5% NPO DISC 1 C4A
....2 255-102C Cap,1000 pf COG 200V Ceramic Dip
Kemet C322C102J2G5CA 5%
1 C2
....2 255-161 CAPACITOR, 160 PF 300V 5% SIVLER
MICA
1 C4B
....2 255-271C CAPACITOR, 270pF 5% 200V
CERAMIC DIPPED
1 C3
....2 350-025 INDUCTOR, 1.5 - 3 UH WITH SHIELD
CAN #47271-021
2 L1,L2
....2 360-026 FILTER, 25 KHZ 10.7 MHZ 1 FL1
....2 500-199 Keps nut 4 x 40 zinc 4CNKEOZ 2
....2 550-084 CONNECTOR,PHONO JACK,PCB
MOUNT
2 J1,J2
....2 580-005 Buss Wire, #22AWG Solid Tinned
Copper
0.04
....2 800-207B PC Board, IF Filter R Receiver 1 PCB
