Broadcast Electronics Marti Electronics SR-30 - Page 55

BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
45
..1 800-207-30 Filter, assembly 30/36 KHz 1
....2 255-161 CAPACITOR, 160 PF 300V 5%
SIVLER MICA
1 C2B
....2 255-241 Capacitor, 240 pf 500v 5% silver
mica CD10FD241J03
1 C2A
....2 255-271C CAPACITOR, 270pF 5% 200V
CERAMIC DIPPED
1 C3
....2 255-361 Capacitor, 360pF 300v 5% silver
mica CD10FA361J03
1 C4
....2 255-750 CAPACITOR, 75 pF 5% NPO DISC 1 C1
....2 330-021 INDUCTOR, 3.3uH AXIAL LEAD
CHOKE
1 C5
....2 350-025 INDUCTOR, 1.5 - 3 UH WITH
SHIELD CAN #47271-021
1 L2
....2 350-030 INDUCTOR, 3.0 - 7 UH W/SHIELD
CAN #47271-023
1 L1
....2 360-024T Filter, 30 KHz 1 FL1
....2 550-084 CONNECTOR,PHONO JACK,PCB
MOUNT
2 J1,J2
....2 800-207B PC Board, IF Filter R Receiver 1 PCB
