46
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
..1 800-207-50 Filter, assembly 50 KHz 1
....2 215-301 CAPACITOR, 300 PF 2.5% 100V
POLYPRO
2 C2A,C2B
....2 255-100 CAPACITOR, 10 PF 5% NPO DISC 1 C3A
....2 255-101C Capacitor, 100pf 5% 200V ceramic
dipped C317C101J2G5CA
1 C1
....2 255-161 CAPACITOR, 160 PF 300V 5%
SIVLER MICA
1 C4B
....2 255-750 CAPACITOR, 75 pF 5% NPO DISC 1 C3B
....2 350-025 INDUCTOR, 1.5 - 3 UH WITH
SHIELD CAN #47271-021
2 L1,L2
....2 360-027 FILTER, 50KHZ 10.7 MHZ 1 FL1
....2 500-199 Keps nut 4 x 40 zinc 4CNKEOZ 2
....2 550-084 CONNECTOR,PHONO JACK,PCB
MOUNT
2 J1,J2
....2 580-005 Buss Wire, #22AWG Solid Tinned
Copper
0.04
....2 800-207B PC Board, IF Filter R Receiver 1
