BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
47
..1 913-2132-
150
ASSY,DUAL WIDE-BAND
CONVERTER,150 MHZ (NOTE)
1
....2 270-120 CAP, SMT, 12PF, 100V 3 C61,C62,C63
....2 350-200 INDUCTOR, SMT, 1812, 56NH 2 L11,L12
....2 350-202 IND, SMT, 1812, 39 NH 2 L10,L13
....2 360-0140 FILTER, HELICAL BANDPASS,
F=140M
2 FL2,FL3
....2 360-0175 FILTER, HELICAL BANDPASS,
F=175M
2 FL6,FL7
....2 361-0145 FILTER, HELICAL BANDPASS,
F=145M
2 FL4,FL5
....2 361-0160 FILTER, HELICAL BANDPASS,
F=160M
1 FL1
....2 361-0162 FILTER, HELICAL BANDPASS,
F=162M
2 FL8,FL9
....2 400-246 IC, VCO, 195-245 MHZ 1 U31
....2 407-0503 EMI SHIELD,MARTI CONVERTER
INPUT
1
....2 427-0061 CONNECTOR, N, PCB, STRAIGHT,
PNL MTG
1 J4
....2 913-2132 ASSY,PCB,DUAL WIDE-BAND
CONVERTER (SBCM)
1
......3 006-1085 CAP,ELECTRO,100
UF,10%,35V,SMD
9 C94,C95,C88,
C105,C130,C124,
C125,C89,C156
......3 006-4775-
350
CAP,ELECTRO,47UF,20%,35V,SM
D
1 C134
......3 007-0470-
006
CAP,470pF,50v,10%,0603 2 C137,C121
......3 007-1022 CAP,CER,100pF,50V,2%,SMD 3 C120,C117,C118
......3 007-1024 CAP,CER,.001uF,50V,10%,SMD 1 C115
......3 007-1044 CAP,CER,0.1uF,50V,10%,SMD
note
14 C1,C4,C5,C6,C7,
C8,C13,C14,C15,
C16,C17,C111,
C119,C34
......3 007-1813-
050
CAP,CER,180
PFD,5%,50V,1206,SMD
1 C102
......3 007-3300 CAP,CER,3.3PF,50V,.25pF,SMD 1 C116
......3 007-3312 CAP,CER,33pF,50V,2%,SMD 4 C2,C3,C110,C114
......3 007-4700-
500
CAP,CER,4.7pF,50V,.25pF,SMD 1 C113
......3 011-7.3728 Crystal,SMT,7.3728 MHz, 50ppm,
Epson MA-506-7.3728M-C2
1 X1
......3 012-280-1 TCXO, SMT, 12.800 MHZ, 1PPM 1 U29
