48
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
......3 070-1054 CAP,TANT,1uF,35V,10%,SMD 36 C18,C9,C10,C23,
C24,C25,C31,C32
,C29,C47,C50,
C51,C53,C54,C57
,C58,C70,C71,
C66,C67,C78,C79
, C73,C74,C87,
C145,C96,C98,
C93,C131,C126,
C128,C90,C123,
C42,C154
......3 070-1064 CAP,TANT,10uF,35V,20%,SMD 1 C138
......3 070-1084 CAP,TANT,100uF,16V,10%,SMD 1 C112
......3 070-2204 CAP,TANT,22uF,25V,10%,SMD 2 C11,C12
......3 070-2265-
L25
CAP,TANT,22 MFD,20%,25V, E
CASE,LOW ESR,SMD
2 C139,C140
......3 070-6854 TANT CAP, 6.8 UF, 16V, SIZE C 1 C108
......3 101-0100 RES,THICK FILM,100,1/8W,SMD 2 R13,R14
......3 102-1000 RES,CHIP,100
OHMS,1/10W,1%,SMD
8 R19,R178,R179,
R181,R185,R188,
R189,R162
......3 102-1001 RES,CHIP,1.00K
OHMS,1/10W,1%,SMD
16 R2,R163,R149,
R164,R165,R192,
R177,R183,R187,
R70,R61,R160,
R55,R56,R57,R58
......3 102-1002 RES,CHIP,10.0K
OHMS,1/10W,1%,SMD
15 R18,R26,R27,
R199,R148,R176,
R193,R60,R63,
R171,R64,R156,
R157,R54,R202
......3 102-1003 RES,CHIP,100K
OHMS,1/10W,1%,SMD
5 R170,R158,R159,
R168,R169
......3 102-1004 RES,CHIP,1.00M
OHMS,1/10W,1%,SMD
1 R53
......3 102-1102 RES,CHIP,11.0K
OHMS,1/10W,1%,SMD
1 R201
......3 102-1103 Res Chip 110K 1/10W 1%,SMD 1 R198
......3 102-1400 RES,CHIP,1.4K
OHMS,1/10W,1%,SMD
1 R28
......3 102-1500 RES,CHIP,150
OHMS,1/10W,1%,SMD
37 R32,R33,R34,R35
,R44,R45,R46,
R47,R75,R76,R77
,R78,R85,R86,
R87,R88,R95,R96
,R97,R98,R116,
R117,R118,R119,
R108,R109,R110,
R111,R137,R138,
R139,R140,R123,
R124,R125,R126,
R175
......3 102-1582 RES,CHIP,15.8 K, 1/10 W, 1% 1 R21
......3 102-1623 Res,Chip 162K 1/10W 1% SMD 1 R196
