BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
51
......3 270-103 Cap, Monolithic chip 10000pF 10%
XR7 Kemet C1206C103J5RACTR
12 C26,C28,C46,C82
,C99,C83,C129,
C133,C146,C148,
C40,C101
......3 270-104 Capacitor, Monolithic Chip 100000pF
1% C1206C104J5RAC Kemet
12 C86,C135,C91,
C107,C132,C147,
C149,C100,C150,
C152,C153,C155
......3 270-682 CAPACITOR, SMT, 1206, 6800 PF,
5%
1 C142
......3 298-106 Cap., Tantalum, SMT, Size B, 10uF,
16V,Kemet T491B106K016AS
2 C106,C103
......3 298-157 Capacitor,Tantalum,SMT,size
X,150uF,16V Kemet
T491X157K016AS
3 C44,C109,C43
......3 330-024 Inductor, 10uH SMT DN12103JTR-
ND DELEVAN 5%
16 L3,L8,L9,L30,L31,
L16,L17,L18,L20,
L21,L19,L22,L25,
L26,L2,L5
......3 350-201 INDUCTOR, SMT, 1812, 82NH 1 L29
......3 360-0600 FILTER, HELICAL BANDPASS,
F=60.0M
2 FL10,FL11
......3 360-0707 FILTER, HELICAL BANDPASS,
F=70.7M
1 FL12
......3 366-0010-
001
IND,10UH,1.5A 2 L27,L28
......3 366-0246 Inductor SMT 246 NH 5%,Maxi
Spring
1 L23
......3 366-0680 IND,CER,680NH,5%,SMD 4 L1,L4,L14,L15
......3 366-2700 IND,1008LS 2.7UH,10%,SMD 1 L24
......3 400-196 IC, SMT, 1.5A STEP-UP
REGULATOR
1 U37
......3 400-295 IC,OP-AMP, GENERAL PURPOSE,
OP295GS
2 U14,U34
......3 401-164 IC, SMT, 8-Bit Ser In, Par Out SR
Phillips 74HC164D
2 U6,U7
......3 401-275 IC,SMT,OP-AMP,LOW NOISE,HIGH
AUDIO BW
4 U3,U4,U32,U36
......3 401-317 IC, SMT, Regulator,Adjustable, 1.5
Amps,National LM317AEMP
1 U38
......3 401-374 IC, OCTAL D FLIP-FLOP W 3-ST
OUT
2 U8,U9
......3 407-0502 EMI SHIELD,MODIFIED 59-
CBSAFN-1.0x1.75x.50
1
......3 413-1206 CHIP,TEST POINT,1206,SMD 3 TP1,TP2,TP3
......3 415-840 Diode, Zener, SMT, 13V, Vishay
BZX84C13TR
2 D6,D8
......3 417-0090 KEYING PLUG 206509-1 AMP 4
......3 417-0265 CONN,BNC,JACK,THREADED,PC
EDGE MOUNT,LOW PROFILE
1 J5
......3 417-8915 CONN, 15 PIN, D, FEMALE, R.A.
FILTERED
2 J1,J3
......3 417-8925 CONN, 25 PIN,D, FEMALE, R.A.
FILTERED
1 J2
