52
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
......3 418-120 DIODE, SMT, 1A, SCHOTTKY
RECTIFIER
1 D9
......3 418-447 Diode, SMT, Zener, 4.7V, Motorola
BZX84C4V7LT1
4 D10,D11,D12,D13
......3 420-141 Transistor, SMT, Darlington, NPN,
Mototrola MMBTA14LT1
15 Q1,Q2,Q4,Q11,
Q12,Q13,Q14,
Q15,Q16,Q17,
Q18,Q19,Q20,
Q25,Q27
......3 431-4400 SOCKET,44-PIN,PLCC,SMD
note
1
......3 439-041 TRANSISTOR, SMT, GENERAL
PURPOSE, NPN
2 Q21,Q3
......3 513-2132 PCB,BLANK,DUAL WIDE BAND
CONVERTER
1
......3 973-2132-U1 KIT,SOFTWARE,SR30/SR40A/SR20
C/SR20M,U1
1 U1
........4 224-8535-
001
IC,MCU,ATMEGA8535,44-PIN
PLCC,SMD
1 U1
