BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
53
..1 913-2132-240 ASSY,DUAL WIDE-BAND
CONVERTER,240 MHZ (NOTE)
1
....2 270-608-1 CAP, SMT, 6.8 PF, 100V 3 C61,C62,C63
....2 350-203 IND, SMT, 1812, 33 NH 2 L11,L12
....2 350-205 IND, SMT, 1812, 22 NH 2 L10,L13
....2 360-0221 FILTER, HELICAL BANDPASS, F=221M 2 FL2,FL3
....2 360-0234 FILTER, HELICAL BANDPASS, F=234M 2 FL4,FL5
....2 360-0240 FILTER, HELICAL BANDPASS, F=240M 1 FL1
....2 360-0246 FILTER, HELICAL BANDPASS, F=246M 2 FL8,FL9
....2 360-0259 FILTER, HELICAL BANDPASS, F=259M 2 FL6,FL7
....2 400-325 IC, VCO, 275-325 MHZ 1 U31
....2 407-0503 EMI SHIELD,MARTI CONVERTER INPUT 1
....2 427-0061 CONNECTOR, N, PCB, STRAIGHT, PNL
MTG
1 J4
....2 913-2132 ASSY,PCB,DUAL WIDE-BAND
CONVERTER (SBCM)
1
......3 006-1085 CAP,ELECTRO,100 UF,10%,35V,SMD 9 C94,C95,C88,
C105,C130,C124
,C125,C89,C156
......3 006-4775-350 CAP,ELECTRO,47UF,20%,35V,SMD 1 C134
......3 007-0470-006 CAP,470pF,50v,10%,0603 2 C137,C121
......3 007-1022 CAP,CER,100pF,50V,2%,SMD 3 C120,C117,C118
......3 007-1024 CAP,CER,.001uF,50V,10%,SMD 1 C115
......3 007-1044 CAP,CER,0.1uF,50V,10%,SMD note 14 C1,C4,C5,C6,C7,
C8,C13,C14,C15,
C16,C17,C111,
C119,C34
......3 007-1813-050 CAP,CER,180 PFD,5%,50V,1206,SMD 1 C102
......3 007-3300 CAP,CER,3.3PF,50V,.25pF,SMD 1 C116
......3 007-3312 CAP,CER,33pF,50V,2%,SMD 4 C2,C3,C110,
C114
......3 007-4700-500 CAP,CER,4.7pF,50V,.25pF,SMD 1 C113
......3 011-7.3728 Crystal,SMT,7.3728 MHz, 50ppm, Epson
MA-506-7.3728M-C2
1 X1
......3 012-280-1 TCXO, SMT, 12.800 MHZ, 1PPM 1 U29
......3 070-1054 CAP,TANT,1uF,35V,10%,SMD 36 C18,C9,C10,C23,
C24,C25,C31,
C32,C29,C47,
C50,C51,C53,
C54,C57,C58,
C70,C71,C66,
C67,C78,C79,
C73,C74,C87,
C145,C96,C98,
C93,C131,C126,
C128,C90,C123,
C42,C154
......3 070-1064 CAP,TANT,10uF,35V,20%,SMD 1 C138
......3 070-1084 CAP,TANT,100uF,16V,10%,SMD 1 C112
......3 070-2204 CAP,TANT,22uF,25V,10%,SMD 2 C11,C12
