Broadcast Electronics Marti Electronics SR-30 - Page 64

54
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
......3 070-2265-L25 CAP,TANT,22 MFD,20%,25V, E
CASE,LOW ESR,SMD
2 C139,C140
......3 070-6854 TANT CAP, 6.8 UF, 16V, SIZE C 1 C108
......3 101-0100 RES,THICK FILM,100,1/8W,SMD 2 R13,R14
......3 102-1000 RES,CHIP,100 OHMS,1/10W,1%,SMD 8 R19,R178,R179,
R181,R185,R188
,R189,R162
......3 102-1001 RES,CHIP,1.00K OHMS,1/10W,1%,SMD 16 R2,R163,R149,
R164,R165,R192
,R177,R183,
R187,R70,R61,
R160,R55,R56,
R57,R58
......3 102-1002 RES,CHIP,10.0K OHMS,1/10W,1%,SMD 15 R18,R26,R27,
R199,R148,R176
,R193,R60,R63,
R171,R64,R156,
R157,R54,R202
......3 102-1003 RES,CHIP,100K OHMS,1/10W,1%,SMD 5 R170,R158,R159
,R168,R169
......3 102-1004 RES,CHIP,1.00M OHMS,1/10W,1%,SMD 1 R53
......3 102-1102 RES,CHIP,11.0K OHMS,1/10W,1%,SMD 1 R201
......3 102-1103 Res Chip 110K 1/10W 1%,SMD 1 R198
......3 102-1400 RES,CHIP,1.4K OHMS,1/10W,1%,SMD 1 R28
......3 102-1500 RES,CHIP,150 OHMS,1/10W,1%,SMD 37 R32,R33,R34,
R35,R44,R45,
R46,R47,R75,
R76,R77,R78,
R85,R86,R87,
R88,R95,R96,
R97,R98,R116,
R117,R118,R119
,R108,R109,
R110,R111,R137
,R138,R139,
R140,R123,R124
,R125,R126,
R175
......3 102-1582 RES,CHIP,15.8 K, 1/10 W, 1% 1 R21
......3 102-1623 Res,Chip 162K 1/10W 1% SMD 1 R196
......3 102-1744 RES,1.74K OHM,1/10W,1% 1 R190
......3 102-1802 Res Chip 18.2 ohm 1/10W 1% SMD 6 R99,R100,R101,
R127,R128,R129
......3 102-2000 RES,CHIP,200 OHM,1/10 W,1% SMD 1 R184
......3 102-2001 RES,CHIP,2.00K OHMS,1/10W,1%,SMD 1 R22
......3 102-2201 RES,CHIP,22.1 OHM,1/10W,1% 3 R79,R80,R71
......3 102-2214 RES,CHIP,2.21K OHM,1/10W,1% 1 R23
......3 102-2490 RES,CHIP,24.9 OHM,1/10W,1% 4 R102,R103,R130
,R132
......3 102-2491 RES,CHIP,2.49K,1/10W,1%,SMD 1 R67
