BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
55
......3 102-2741 RES,CHIP,2.74K OHMS,1/10W,1%,SMD 14 R37,R43,R74,
R84,R94,R115,
R107,R136,R122
,R144,R146,R30,
R20,R204
......3 102-3010 RES, CHIP, 301 OHMS, 1/10W, 1%, SMD 1 R66
......3 102-3011 RES,CHIP,3.01K OHMS,1/10W,1%,SMD 2 R24,R29
......3 102-3321 RES,CHIP,3.32K OHMS,1/10W,1%,SMD 2 R3,R69
......3 102-3832 RES, CHIP, 38.3 KOHMS, 1/10W, 1%,
SMD
1 R203
......3 102-3901 RES,CHIP,3.9K OHMS,1/10W,1%,SMD 1 R65
......3 102-3902 Res, Chip 39.2 ohms 1/10W 1% SMD 2 R104,R131
......3 102-3925 RES,CHIP,39.2 K OHM,1/10 W,1% 1 R197
......3 102-4221 RES,CHIP,4.22K,1/10W,1%,SMD 18 R36,R38,R41,
R42,R72,R73,
R82,R83,R92,
R93,R113,R114,
R120,R121,R105
,R106,R134,
R135
......3 102-4302 Res,Chip 43.2 ohms 1/10W 1% SMD 1 R81
......3 102-4421 RES,CHIP,4.42K OHMS,1/10W,1%,SMD 1 R25
......3 102-4750 RES,CHIP,475 OHMS,1/10W,1%,SMD 2 R150,R191
......3 102-4751 RES,CHIP,4.75K OHMS,1/10W,1%,SMD 32 R1,R4,R5,R6,R7,
R8,R9,R10,R11,
R12,R15,R16,
R17,R141,R151,
R142,R152,R194
,R195,R39,R40,
R166,R167,R172
,R173,R143,R59,
R161,R48,R50,
R51,R52
......3 102-4990 RES,499 OHM,1/10W,1% 1 R68
......3 102-4991 RES,CHIP,49.9 OHMS,1/10W,1%,SMD 1 R180
......3 102-5112 RES,CHIP,51.1 OHM,1/10W,1% 2 R112,R133
......3 102-5143 RES,5.1K OHMS,1/10W,1%,SMD 6 R145,R147,R182
,R186,R31,R205
......3 102-6040 RES,604 OHM,1/10W,1% 1 R174
......3 102-6341 RES,CHIP,6.34K,1/10W,1%,SMD 2 R154,R155
......3 102-6811 RES,CHIP,6.81K,1/10W,1%,SMD 1 R200
......3 102-7680 RES,CHIP,768 OHMS,1/10W,1%,SMD 1 R62
......3 198-2024 TRMR,2K OHMS,TOP ADJUST,10
TURN,SMD
1 R153
......3 204-0914 DIODE,SWITCHING,MMBD914LT1,SMD 4 D2,D3,D4,D5
......3 204-3102 DIODE,MMBV3102LT1,SMD 1 D7
......3 204-5000 VOLTAGE,REFERENCE,5.0V,SMD 1 D1
......3 210-0093 TRANSISTOR,BFR93A,SOT-23,SMD 2 Q23,Q24
......3 216-0064 TSTR SMT Darlington PNP 1 Q26
......3 216-0310 TSTR,MMBFU310LT1,SMD 1 Q22
......3 220-1020 IC, RF Switch SP4T Absorptive 2 U12,U17
......3 220-4052-002 IC,4052 DUAL 4-CH MUX,SMD 1 U5
......3 220-4521 IC Digital Attenuator o-31 db 1 U11
