Broadcast Electronics Marti Electronics SR-30 - Page 66

56
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
......3 220-4527 Freq Mixer 50-1000 MHz +17 DBM LO 2 U18,U22
......3 220-4611 IC, DIG ATTEN, 0-31 DB, 0.5 DB STEPS 1 U15
......3 220-8065 IC, HIGH SPEED FET OP-AMP 1 U33
......3 220-9832 IC, 25 MHZ DDS 1 U30
......3 221-0006 RF Amp GALI-4 SMD Wideband 50 Ohm 9 U10,U13,U19,
U20,U21,U23,
U24,U25,U26
......3 221-4110 RF PLL FREQUENCY SYNTHESIZER 1 U28
......3 221-4111 IC PLL SYN DM Prescalers 1.2GHz 1 U27
......3 224-0333 SWITCH,QUAD,ADG333ABRS,20-PIN
SSOP,SMD
1 U16
......3 224-0809 IC,MCU RESET,MAX809L,4.63V,SOT-
23,SMD
1 U2
......3 270-101 Cap., monolithic chip, 100 pf 50v 5%
Kemet C1206C101J5GAC
1 C141
......3 270-102 Cap,monolithic,1000pf 50v
5%KemetC1206C102J5GACTR marked
37 C20,C21,C22,
C27,C30,C36,
C41,C45,C48,
C49,C52,C55,
C56,C59,C60,
C65,C68,C69,
C72,C75,C76,
C77,C80,C81,
C92,C97,C136,
C143,C144,C84,
C85,C127,C122,
C64,C38,C39,
C37
......3 270-103 Cap, Monolithic chip 10000pF 10% XR7
Kemet C1206C103J5RACTR
12 C26,C28,C46,
C82,C99,C83,
C129,C133,C146
,C148,C40,C101
......3 270-104 Capacitor, Monolithic Chip 100000pF 1%
C1206C104J5RAC Kemet
12 C86,C135,C91,
C107,C132,C147
,C149,C100,
C150,C152,C153
,C155
......3 270-682 CAPACITOR, SMT, 1206, 6800 PF, 5% 1 C142
......3 298-106 Cap., Tantalum, SMT, Size B, 10uF,
16V,Kemet T491B106K016AS
2 C106,C103
......3 298-157 Capacitor,Tantalum,SMT,size
X,150uF,16V Kemet T491X157K016AS
3 C44,C109,C43
......3 330-024 Inductor, 10uH SMT DN12103JTR-ND
DELEVAN 5%
16 L3,L8,L9,L30,L31
,L16,L17,L18,L20
,L21,L19,L22,L25
,L26,L2,L5
......3 350-201 INDUCTOR, SMT, 1812, 82NH 1 L29
......3 360-0600 FILTER, HELICAL BANDPASS, F=60.0M 2 FL10,FL11
......3 360-0707 FILTER, HELICAL BANDPASS, F=70.7M 1 FL12
......3 366-0010-001 IND,10UH,1.5A 2 L27,L28
......3 366-0246 Inductor SMT 246 NH 5%,Maxi Spring 1 L23
......3 366-0680 IND,CER,680NH,5%,SMD 4 L1,L4,L14,L15
......3 366-2700 IND,1008LS 2.7UH,10%,SMD 1 L24
