BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
57
......3 400-196 IC, SMT, 1.5A STEP-UP REGULATOR 1 U37
......3 400-295 IC,OP-AMP, GENERAL PURPOSE,
OP295GS
2 U14,U34
......3 401-164 IC, SMT, 8-Bit Ser In, Par Out SR Phillips
74HC164D
2 U6,U7
......3 401-275 IC,SMT,OP-AMP,LOW NOISE,HIGH
AUDIO BW
4 U3,U4,U32,U36
......3 401-317 IC, SMT, Regulator,Adjustable, 1.5
Amps,National LM317AEMP
1 U38
......3 401-374 IC, OCTAL D FLIP-FLOP W 3-ST OUT 2 U8,U9
......3 407-0502 EMI SHIELD,MODIFIED 59-CBSAFN-
1.0x1.75x.50
1
......3 413-1206 CHIP,TEST POINT,1206,SMD 3 TP1,TP2,TP3
......3 415-840 Diode, Zener, SMT, 13V, Vishay
BZX84C13TR
2 D6,D8
......3 417-0090 KEYING PLUG 206509-1 AMP 4
......3 417-0265 CONN,BNC,JACK,THREADED,PC EDGE
MOUNT,LOW PROFILE
1 J5
......3 417-8915 CONN, 15 PIN, D, FEMALE, R.A.
FILTERED
2 J1,J3
......3 417-8925 CONN, 25 PIN,D, FEMALE, R.A.
FILTERED
1 J2
......3 418-120 DIODE, SMT, 1A, SCHOTTKY RECTIFIER 1 D9
......3 418-447 Diode, SMT, Zener, 4.7V, Motorola
BZX84C4V7LT1
4 D10,D11,D12,
D13
......3 420-141 Transistor, SMT, Darlington, NPN,
Mototrola MMBTA14LT1
15 Q1,Q2,Q4,Q11,
Q12,Q13,Q14,
Q15,Q16,Q17,
Q18,Q19,Q20,
Q25,Q27
......3 431-4400 SOCKET,44-PIN,PLCC,SMD note 1
......3 439-041 TRANSISTOR, SMT, GENERAL
PURPOSE, NPN
2 Q21,Q3
......3 513-2132 PCB,BLANK,DUAL WIDE BAND
CONVERTER
1
......3 973-2132-U1 KIT,SOFTWARE,SR30/SR40A/SR20C/SR
20M,U1
1 U1
........4 224-8535-001 IC,MCU,ATMEGA8535,44-PIN PLCC,SMD 1 U1
