BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
......3 102-3321 RES,CHIP,3.32K OHMS,1/10W,1%,SMD 2 R3,R69
......3 102-3832 RES, CHIP, 38.3 KOHMS, 1/10W, 1%,
SMD
1 R203
......3 102-3901 RES,CHIP,3.9K OHMS,1/10W,1%,SMD 1 R65
......3 102-3902 Res, Chip 39.2 ohms 1/10W 1% SMD 2 R104,R131
......3 102-3925 RES,CHIP,39.2 K OHM,1/10 W,1% 1 R197
......3 102-4221 RES,CHIP,4.22K,1/10W,1%,SMD 18 R36,R38,R41,R42,
R72,R73,R82,R83,
R92,R93,R113,R114,
R120,R121,R105,
R106,R134,R135
......3 102-4302 Res,Chip 43.2 ohms 1/10W 1% SMD 1 R81
......3 102-4421 RES,CHIP,4.42K OHMS,1/10W,1%,SMD 1 R25
......3 102-4750 RES,CHIP,475 OHMS,1/10W,1%,SMD 2 R150,R191
......3 102-4751 RES,CHIP,4.75K OHMS,1/10W,1%,SMD 32 R1,R4,R5,R6,R7,R8,
R9,R10,R11,R12,
R15,R16,R17,R141,
R151,R142,R152,
R194,R195,R39,R40,
R166,R167,R172,
R173,R143,R59,
R161,R48,R50,R51,
R52
......3 102-4990 RES,499 OHM,1/10W,1% 1 R68
......3 102-4991 RES,CHIP,49.9 OHMS,1/10W,1%,SMD 1 R180
......3 102-5112 RES,CHIP,51.1 OHM,1/10W,1% 2 R112,R133
......3 102-5143 RES,5.1K OHMS,1/10W,1%,SMD 6 R145,R147,R182,
R186,R31,R205
......3 102-6040 RES,604 OHM,1/10W,1% 1 R174
......3 102-6341 RES,CHIP,6.34K,1/10W,1%,SMD 2 R154,R155
......3 102-6811 RES,CHIP,6.81K,1/10W,1%,SMD 1 R200
......3 102-7680 RES,CHIP,768 OHMS,1/10W,1%,SMD 1 R62
......3 198-2024 TRMR,2K OHMS,TOP ADJUST,10
TURN,SMD
1 R153
......3 204-0914 DIODE,SWITCHING,MMBD914LT1,SMD 4 D2,D3,D4,D5
......3 204-3102 DIODE,MMBV3102LT1,SMD 1 D7
......3 204-5000 VOLTAGE,REFERENCE,5.0V,SMD 1 D1
......3 210-0093 TRANSISTOR,BFR93A,SOT-23,SMD 2 Q23,Q24
......3 216-0064 TSTR SMT Darlington PNP 1 Q26
......3 216-0310 TSTR,MMBFU310LT1,SMD 1 Q22
......3 220-1020 IC, RF Switch SP4T Absorptive 2 U12,U17
......3 220-4052-
002
IC,4052 DUAL 4-CH MUX,SMD 1 U5
......3 220-4521 IC Digital Attenuator o-31 db 1 U11
......3 220-4527 Freq Mixer 50-1000 MHz +17 DBM LO 2 U18,U22
......3 220-4611 IC, DIG ATTEN, 0-31 DB, 0.5 DB STEPS 1 U15
......3 220-8065 IC, HIGH SPEED FET OP-AMP 1 U33
......3 220-9832 IC, 25 MHZ DDS 1 U30
......3 221-0006 RF Amp GALI-4 SMD Wideband 50 Ohm 9 U10,U13,U19,U20,
U21,U23,U24,U25,U
26
......3 221-4110 RF PLL FREQUENCY SYNTHESIZER 1 U28
