BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
61
......3 221-4111 IC PLL SYN DM Prescalers 1.2GHz 1 U27
......3 224-0333 SWITCH,QUAD,ADG333ABRS,20-PIN
SSOP,SMD
1 U16
......3 224-0809 IC,MCU RESET,MAX809L,4.63V,SOT-
23,SMD
1 U2
......3 270-101 Cap., monolithic chip, 100 pf 50v 5%
Kemet C1206C101J5GAC
1 C141
......3 270-102 Cap,monolithic,1000pf 50v
5%KemetC1206C102J5GACTR marked
37 C20,C21,C22,C27,
C30,C36,C41,C45,
C48,C49,C52,C55,
C56,C59,C60,C65,
C68,C69,C72,C75,
C76,C77,C80,C81,
C92,C97,C136,C143,
C144,C84,C85,C127,
C122,C64,C38,C39,
C37
......3 270-103 Cap, Monolithic chip 10000pF 10% XR7
Kemet C1206C103J5RACTR
12 C26,C28,C46,C82,
C99,C83,C129,C133,
C146,C148,C40,
C101
......3 270-104 Capacitor, Monolithic Chip 100000pF 1%
C1206C104J5RAC Kemet
12 C86,C135,C91,C107,
C132,C147,C149,
C100,C150,C152,
C153,C155
......3 270-682 CAPACITOR, SMT, 1206, 6800 PF, 5% 1 C142
......3 298-106 Cap., Tantalum, SMT, Size B, 10uF,
16V,Kemet T491B106K016AS
2 C106,C103
......3 298-157 Capacitor,Tantalum,SMT,size
X,150uF,16V Kemet T491X157K016AS
3 C44,C109,C43
......3 330-024 Inductor, 10uH SMT DN12103JTR-ND
DELEVAN 5%
16 L3,L8,L9,L30,L31,
L16,L17,L18,L20,L21
,L19,L22,L25,L26,L2,
L5
......3 350-201 INDUCTOR, SMT, 1812, 82NH 1 L29
......3 360-0600 FILTER, HELICAL BANDPASS, F=60.0M 2 FL10,FL11
......3 360-0707 FILTER, HELICAL BANDPASS, F=70.7M 1 FL12
......3 366-0010-
001
IND,10UH,1.5A 2 L27,L28
......3 366-0246 Inductor SMT 246 NH 5%,Maxi Spring 1 L23
......3 366-0680 IND,CER,680NH,5%,SMD 4 L1,L4,L14,L15
......3 366-2700 IND,1008LS 2.7UH,10%,SMD 1 L24
......3 400-196 IC, SMT, 1.5A STEP-UP REGULATOR 1 U37
......3 400-295 IC,OP-AMP, GENERAL PURPOSE,
OP295GS
2 U14,U34
......3 401-164 IC, SMT, 8-Bit Ser In, Par Out SR Phillips
74HC164D
2 U6,U7
......3 401-275 IC,SMT,OP-AMP,LOW NOISE,HIGH
AUDIO BW
4 U3,U4,U32,U36
......3 401-317 IC, SMT, Regulator,Adjustable, 1.5
Amps,National LM317AEMP
1 U38
......3 401-374 IC, OCTAL D FLIP-FLOP W 3-ST OUT 2 U8,U9
......3 407-0502 EMI SHIELD,MODIFIED 59-CBSAFN-
1.0x1.75x.50
1
