Broadcom P411W-32P User Manual

Broadcom P411W-32P-UG104
12
P411W-32P PCIe 4.0 User Guide NVMe Switch Adapter
7 Cable Support
Broadcom supports the following cables for use with the adapter.
8 P411W-32P NVMe Switch Adapter Characteristics
8.1 LEDs
The adapter has one heartbeat LED and one system error status LED. The LED blinks at 1 Hz to indicate that the firmware
on the board is operational. The system error status LED is lit when a system error occurs.
8.2 Physical Characteristics
The adapter is a 6.127 in. × 2.712 in. (155.65 mm × 68.90 mm) board. The component height on the top and bottom of the
adapter complies with the PCI Express Card Electromechanical Specification Revision 3.0. The following figure shows the
adapter board layout.
Table 5 Mixed Drive-to-Port Connection Example
Adapter Label Tool Mapping Port Number Drive
C0 C0.1 0 x2
2x2
C0.0 4 x1
5x1
6x1
7x1
Table 6 Supported NVMe Switch Adapter Cables
MPN Cable Description Adapter Connector Backplane Connector
05-60001-00 x8 8654 to 2x4 8612, AltWiring 1M 1 x8 SFF-8654 Slimline Two x4 SFF-8612 OCuLink
05-60002-00 x8 8654 to 2x4 8643 (W), SMC 1M 1 x8 SFF-8654 Slimline Two x4 SFF-8643 Mini-SAS HD
05-60004-00 x8 8654 to 2x4 8654, 9402 1M 1 x8 SFF-8654 Slimline Two x4 SFF-8654 Slimline
05-60005-00 x8 8654 to 2xU.2 Direct, 1M 1 x8 SFF-8654 Slimline Two U.2 SFF-8639
05-60006-00 x8 8654 to 8xU.3 Direct 1M 1 x8 SFF-8654 Slimline Eight U.3 SFF-8639
05-60007-00 x8 8654 to 1x8 8654, 9402 1M 1 x8 SFF-8654 Slimline One x8 SFF-8654 (SlimSAS)

Broadcom P411W-32P Specifications

General

Brand	Broadcom
Model	P411W-32P
Category	Adapter
Language	English
