BROCE FMJ470

SCHEMATICS

(Hydraulic Diagram)

ITEM NO. PART # DESCRIPTION QTY.

1 513376 5 Spool Valve Tank Return Hose Assembly 1

2 513404 Broom Valve Tank Return Assembly 1

3 513426 Auxiliary Pump Hose Assembly 1

4 513404 Broom Valve Tank Return Assembly 1

5 513402 Broom Valve Hose Assembly 1

6 513388 Broom Motor Hose Assembly 2

7 513398 Orbitrol Hose Assembly 1

8 513397 Orbitrol Tank Return Hose Assembly 1

9 513374 5 Spool Valve Supply Hose Assembly 1

10 513366 Angle Cylinder Hose Assembly Piston Side 1

11 513368 Angle Cylinder Hose Assembly Rod Side 1

12 513364 Lift Cylinder Hose Assembly Rod Side 1

13 513362 Lift Cylinder Hose Assembly Piston Side 1

14 513372 Side Shift Hose Assembly Rod Side 1

15 513370 Side Shift Hose Assembly Piston Side 1

16 513386 Foot Valve Tank Return Hose Assembly 1

17 513360 Drive Motor Hose Assembly 2

18 513378 Drive Motor Tank Return Hose Assembly 1

19 513410 Brake Valve Hose Assembly 1

20 513410 Forward Pedal Hose Assembly 1

21 513380 Reverse Pedal Hose Assembly 1

22 513384 Foot Valve Charve Pressure Hose Assembly 1

23 513428 Main Pump Tnak Return Hose Assembly 1

24 513412 Brake Valve Tank Return Hose Assembly 1

25 513418 Oil Cooler to Filter Hose Assembly 1

26 513400 Steering Cylinder Tank Return Hose Assembly 1

27 513416 Filter Tank Return Hose Assembly 1

28 513424 Tank to Auxiliary Suction Filter Hose Assembly 1

29 513420 Tank to Main Suction Filter Hose Assembly 1

30 513422 Main Pump Hose Assembly 1

31 513426 Auxiliary Pump Hose Assembly 1

32 513392 Left Setting Cylinder Hose Assembly Piston Side 1

33 513390 Right Setting Cylinder Hose Assembly Piston Side 1

34 513394 Steering Cylinder Crosslink Hose Assembly 1
