TABLE 4.1
Technical specifications – MBP1-A
TABLE 4.2
Technical specifications – MBPF-A
Firing rate 0.65 0.75 0.85 1.00
Input (BTU/h) 90 500 104 500 118 000 139 000
Capacity (BTU/h) 76 000 87 000 98 000 115 000
Stack draft (chimney)
BECKETT BURNER, CHIMNEY INSTALLATION
Low firing rate baffle
Static disc, model
Nozzle (Delavan) - 100 PSIG pump pressure 0.65 X 80W 0.75 X 80W 0.85 X 80W 1.00 X 80W
RIELLO BURNER, CHIMNEY INSTALLATION
Nozzle (Delavan) 0.50 X 80W 0.65 X 80W 0.75 X 80W 0.85 X 80W
Combustion air adjustment (turbulator/damper) 1/2 1.5/2 2.5/3 3/4
Pump pressure 170 130 130 140
Volts - Hertz - Phase
Operating voltage range
Rated current (Amps)
Motor (HP) / number of speeds
Blower wheel size (in.)
Filter quantity and size
Blower Speed at 0.25" w.c. Static Pressure Med-Lo Med-Lo Med-Hi High
Blower Speed at 0.50" w.c. Static Pressure
RATING AND PERFORMANCE
AFG-F3 (Insertion tube 5 5/8)
YES
R40-F3 (Insertion tube 5 11/16)
104 - 132
115 - 60 - 1
1/3 HP, 4 speeds
10 X 10
(1) 20" X 20"
Firing rate 0.65 0.75 0.85 1.00
Pump pressure (PSIG) 100 100 100 100
Input (BTU/h) 90 500 104 500 118 000 139 000
Capacity (BTU/h) 76 000 87 000 98 000 115 000
Stack draft (chimney)
BECKETT BURNER, CHIMNEY INSTALLATION
Low firing rate baffle
Static disc, model
Nozzle (Delavan) - 100 PSIG pump pressure 0.65 X 80W 0.75 X 80W 0.85 X 80W 1.00 X 80W
RIELLO BURNER, CHIMNEY INSTALLATION
Nozzle (Delavan) 0.50 X 80W 0.65 X 80W 0.75 X 80W 0.85 X 80W
Combustion air adjustment (turbulato/damper) 1/2 1.5/2 2.5/3 3/4
Pump pressure 170 130 130 140
Volts - Hertz - Phase
Operating voltage range
Rated current (Amps)
Motor (HP) / number of speeds
Blower wheel size (in.)
Filter quantity and size
Blower Speed at 0.25"w.c. Static Pressure Med-Lo Med-Lo Med-Hi High
Blower Speed at 0.50"w.c. Static Pressure Med-Lo Med-Hi High N/A
1/3 HP, 4 speeds
10 X 10
(1) 20" X 20"
115 - 60 - 1
104 - 132
AFG-F3 (Insertion tube 5 5/8)
YES
3 3/8" #31646
R40-F3 (Insertion tube 5 11/16)
