Specifi cations
7.1 Materials of Construction
Housing: A 351 GR CF8M (316 Stainless Steel)
Measuring Unit
End Plates and Body: A 351 GR CF8M
(316 Stainless Steel)
Rotors/Rotor Shafts: Aluminum Rotor,
Anodizied 17-4 PH Stainless Steel Shaft
Timing Gears: 416 Stainless Steel
Bearings: Ceramic/Stainless Steel
Elastomers: Viton A®, Low swell Nitrile,
Viton F®, or Fluoro Silicon
are standard
(other options available)
UMB Housing*: A356 T6 Cast Aluminium
* This part is not wetted.
Electrical Details
Pick off:
Non Wetted Reluctance Type
Sine Wave Amplitude: 40 mV P-P, min.
Preamplifi er:
Supply Voltage:9 to 28 VDC
Outputs (Jumper selectable):
Square wave: 0 to 5 KHz
5 V Powered Pulse: 0 – 5 VDC, 20 mA Max
Variable Voltage Pulses:
0 to Supply Voltage Less 5%
70 mA max
Open Collector:
Max voltage: 30 VDC
Max current: 125 mA
Max power: 0.5 W
Performance
SB25X Linearity Standard Rotors
+/- 0.15% Over Standard Flow Range
+/- 0.25% Over Extended Flow Range
Repeatability: +/- 0.02%
Viscosity Range: 0.2 - 5 cP
Operating Temperatures Limits:
Dependant on pick off type and O-Ring
seals used, see Table 1.
To convert pressure drop value to the actual
process fl uid, use the following equation:
ΔPA = (cPA)
0.25
*(SGA)
0.75
* ΔPm
ΔPA = Pressure Drop on Actual Fluid in PSI
cPA = Viscosity of Actual Fluid in cP
SGA = Density of Actual Fluid in SG
ΔPm = Pressure Drop on Mineral Spirits (See Figure
3 on Page 6 for Reference.)
Pick Off Type Seal Material
Minimum Operating Temp Maximum Operating Temp
°F °C °F °C
Standard Viton A -15 -25 167 75
Standard Viton F -15 -25 167 75
Standard Fluoro Silicon -40 -40 167 75
High Temp Vitron A 14 -10 230 110
High Temp Vitron F 14 -10 230 110
High Temp Fluoro Silicon 14 -10 230 110
Table 1: Operating Temperature Limits
