BRONKHORST IN-FLOW - Page 38

analog / RS232
FLOW-BUS / Modbus
DeviceNet
PROFIBUS
EtherCAT/PROFINET
analog / RS232
FLOW-BUS / DeviceNet / Modbus
PROFIBUS
Dimensions digital cases
One of these digital case assemblies replaces the case assembly as drawn in the dimensional drawing.
Please note that the height increases when a contra connector is used.
Dimensions are in millimeters unless otherwise mentioned.
Dimensions subject to change without notice.
Tolerances ±0.5
unless otherwise mentioned
Doc. Nr.: 7.05.445H
Date: 21-07-2015
