Brookeld Engineering Labs., Inc. Page 32 Manual No. M/03-165-D0410
III.3.2 Time to Torque
On entry to this mode, the user is presented with the following screen display:
TIMED TO TORQUE
SET TORQUE:00% èê
Figure III-22
Using the UP or DOWN ARROW keys, the user enters a value for the torque level that you wish to
reach.
Note: The value for torque must be other than zero (0) and less than or equal to ninety-
nine (99) percent or you will not be able to continue.
At this point, the user presses the OPTIONS/TAB key and the screen shown in Figure III-23
appears:
TIME TO TORQUE
SELECT RPM: 30 èê
Figure III-23
Using the UP or DOWN ARROW keys, the user selects a speed from the currently selected speed
set. If you had opted to use the LVRV sequential or interleaved speed sets, all those speeds
would be available by pressing the UP or DOWN ARROW keys. Conversely, if the user had
selected a custom speed set, you would be limited to those speeds comprising the custom
speed set. After selecting the speed, the user may press any one of three keys to continue:
the OPTIONS/TAB key, the MOTOR ON/OFF/ESCAPE key and the ENTER/AUTORANGE key. If the user
presses the OPTIONS/TAB key you will return to the torque input screen of Figure III-22 where
you may change the torque input if so desired. Therefore, continued pressing of the OPTIONS/
TAB
key will toggle between the torque input screens and the motor input screen. A press of
the MOTOR ON/OFF/ESCAPE key will cancel the time to torque operation and take the user back
to the screen of Figure III-13. Finally, pressing the ENTER/AUTORANGE key will cause the DV-
II+Pro to accept and store in EEPROM the new values (only) for the torque level and the
selected motor speed.
That done, the user is presented with the following screen:
TIME TO TORQUE
ENTER TO START
Figure III-24
At this point the user must press the ENTER/AUTORANGE key to begin the timed stop operation.
Any other key press will be ignored except the MOTOR ON/OFF/ESCAPE key which will cancel the
process and take the user back to the screen of Figure III-22 where you will have to begin all
over again.
