Wells-Brookfield Cone/Plate Viscometer Full Scale Ranges
3.0° Cone Spindle
100.0 200.0 122.88 983.0
50.0 100.0 245.76 1,966.0
20.0 40.0 614.40 4,915.0
10.0 20.0 1,228.80 9,830.0
5.0 10.0 2,457.60 19,660.0
2.5 5.0 4,915.20 39,320.0
1.0 2.0 12,288.00 98,300.0
0.5 1.0 24,576.00 196,600.0
1.565° Cone Spindle
100.0 384.00 64.0 512.0
50.0 192.00 128.0 1,024.0
20.0 76.80 320.0 2,560.0
10.0 38.40 6,400.0 5,120.0
5.0 19.20 1,280.0 10,240.0
2.5 9.60 2,560.0 20,480.0
1.0 3.84 6,400.0 51,200.0
0.5 1.92 12,800.0 102,400.0
0.8° Cone Spindle
100.0 750.00 32.7
50.0 375.00 65.4
20.0 150.00 163.5
10.0 75.00 327.0
5.0 37.50 654.0
2.5 18.75 1,308.0
1.0 7.50 3,270.0
0.5 3.75 6,540.0
RVTCP Viscometer
SPEED SHEAR RATE CONE # CP-41 CONE # CP-52
(RPM) (SEC
-1
) 2 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-42 CONE # CP-51
(RPM) (SEC
-1
) 1 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-40
(RPM) (SEC
-1
) 0.5 ml SAMPLE
3.0° Cone Spindle
60.0 120.0 19.2 155.33
30.0 60.0 38.4 310.66
12.0 24.0 96.0 776.64
6.0 12.0 192.0 1,553.30
3.0 6.0 384.0 3,106.60
1.5 3.0 768.0 6,213.10
0.6 1.2 1,920.0 15,532.80
0.3 0.6 3,840.0 31,065.60
1.565° Cone Spindle
60.0 230.00 10.00 80.90
30.0 115.00 20.00 161.80
12.0 46.00 50.00 404.50
6.0 23.00 100.00 809.00
3.0 11.50 200.00 1,618.00
1.5 5.75 400.00 3,236.00
0.6 2.30 1,000.00 8,090.00
0.3 1.15 2,000.00 16,180.00
0.8° Cone Spindle
60.0 450.00 5.14
30.0 225.00 10.28
12.0 90.00 25.70
6.0 45.00 51.40
3.0 22.50 102.80
1.5 11.25 205.60
0.6 4.50 514.00
0.3 2.25 1,028.00
LVTCP Viscometer
SPEED SHEAR RATE CONE # CP-41 CONE # CP-52
(RPM) (SEC
-1
) 2 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-42 CONE # CP-51
(RPM) (SEC
-1
) 1 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-40
(RPM) (SEC
-1
) 0.5 ml SAMPLE
