Brookfield Engineering Laboratories, Inc. Page 17 Manual No. M/85-150-N898
Viscometer Ranges in Centipoise (1 cP = 1 mPa•s)
Viscosity = Dial Reading x Factor
Factor = Viscometer Range/100
Note: When calibrating 2.4cm diameter cone spindles CP-51 or CP-52 at shear rates greater than
384 sec
-1
, use Brookfield Viscosity Standards 5,000 cP or lower.
3.0° Cone Spindle
100.0 200.0 983.0 7,864.0
50.0 100.0 1,966.0 15,728.0
20.0 40.0 4,915.0 39,320.0
10.0 20.0 9,830.0 78,640.0
5.0 10.0 19,660.0 157,280.0
2.5 5.0 39,320.0 314,560.0
1.0 2.0 98,300.0 786,400.0
0.5 1.0 196,600.0 1,572,800.0
1.565° Cone Spindle
100.0 384.00 512.0 4,096.0
50.0 192.00 1,024.0 8,192.0
20.0 76.80 2,560.0 20,480.0
10.0 38.40 5,120.0 40,960.0
5.0 19.20 10,240.0 81,920.0
2.5 9.60 20,480.0 163,840.0
1.0 3.84 51,200.0 409,600.0
0.5 1.92 102,400.0 819,200.0
0.8° Cone Spindle
100.0 750.00 262.0
50.0 375.00 524.0
20.0 150.00 1,310.0
10.0 75.00 2,620.0
5.0 37.50 5,240.0
2.5 18.75 10,480.0
1.0 7.50 26,200.0
0.5 3.75 52,400.0
HBTCP Viscometer
SPEED SHEAR RATE CONE # CP-41 CONE # CP-52
(RPM) (SEC
-1
) 2 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-42 CONE # CP-51
(RPM) (SEC
-1
) 1 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-40
(RPM) (SEC
-1
) 0.5 ml SAMPLE
3.0° Cone Spindle
100.0 200.0 245.76 1,966.0
50.0 100.0 491.52 3,932.0
20.0 40.0 1,228.80 9,830.0
10.0 20.0 2,457.60 19,660.0
5.0 10.0 4,915.20 39,320.0
2.5 5.0 9,830.40 78,640.0
1.0 2.0 24,576.00 196,600.0
0.5 1.0 49,152.00 393,200.0
1.565° Cone Spindle
100.0 384.00 128.0 1,024.0
50.0 192.00 256.0 2,048.0
20.0 76.80 640.0 5,120.0
10.0 38.40 1,280.0 10,240.0
5.0 19.20 2,560.0 20,480.0
2.5 9.60 5,120.0 40,960.0
1.0 3.84 12,800.0 102,400.0
0.5 1.92 25,600.0 204,800.0
0.8° Cone Spindle
100.0 750.00 65.4
50.0 375.00 130.8
20.0 150.00 327.0
10.0 75.00 654.0
5.0 37.50 1,308.0
2.5 18.75 2,616.0
1.0 7.50 6,540.0
0.5 3.75 13,080.0
HATCP Viscometer
SPEED SHEAR RATE CONE # CP-41 CONE # CP-52
(RPM) (SEC
-1
) 2 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-42 CONE # CP-51
(RPM) (SEC
-1
) 1 ml SAMPLE 0.5 ml SAMPLE
SPEED SHEAR RATE CONE # CP-40
(RPM) (SEC
-1
) 0.5 ml SAMPLE
Wells-Brookfield Cone/Plate Viscometer Full Scale Ranges
