Site Manual
Alarm 2000 Iss 5
49
OPTIONS
Where additional modules have been added to the system the following additional tests
shall be carried out, as required.
Power supply monitoring
Note: The operating parameters and threshold voltages are factory pre-set, the
following test is to confirm functionality.
18. Disconnect the standby supply, check that within 1 hour the power supply fault
indicator illuminates, and ensure that the PSU fault output functions correctly
Yes No Not Applicable
Residential Sprinkler
19. Open circuit and short circuit the end of line device on the sprinkler system flow
switch circuit, or conduct other appropriate tests to ensure that fault and alarm
conditions are operating correctly, and ensure that each associated output
operates as required.
Yes No Not Applicable
20. Open circuit and short circuit the end of line device on the monitored valve circuit,
or conduct other appropriate tests to ensure that fault and tamper conditions are
operating correctly, and ensure that each associated output operates as required.
Yes No Not Applicable
Manual Override
21. Operate each override control in turn and check that each output and associated
ancillary equipment functions correctly, and ensure each control indicator
illuminates.
Yes No Not Applicable
Ancillary Control
22. With the emergency lighting controls set to automatic, place the system into an
alarm condition, ensure that the emergency lighting is activated whilst the system
is in that condition.
Yes No Not Applicable
23. With the Heating / Cooling controls set to automatic, place the system into an alarm
condition, ensure that the Heating / Cooling output is activated whilst the system is
in that condition.
Yes No Not Applicable
24. Ensure that the ‘OFF’ function for the Heating / Cooling functions correctly, and the
control indicator illuminates.
Yes No Not Applicable
