Brother BAS-311F-0 Specifications And Parts List

BAS-311F-0 14/22
2002.1
Inner clamping device
Ref. No. Part name Part code Q’ty
1 Inner clamping device set S44793-009 1
1-1 Work clamp clank assy, LA S12633-209 1
1-1-1 Work clamp crank holder, A S12634-009 1
1-1-2 Work clamp crank holder, B S12635-009 1
1-1-3 Work clamp crank holder, C S12636-001 1
1-1-4 Washer, crank holder S12641-009 1
1-1-5 Bolt, socket SM4.37 – 40 x 12 018681-232 2
1-1-6 Reverse cylinder bracket S12638-009 1
1-1-7 Bolt, socket M3 x 12 018301-236 2
1-1-8 Bolt, socket M3 x 10 018301-036 2
1-1-9 Work clamp clank, LA S05665-001 1
1-1-10 Reverse gear 154235-001 1
1-1-11 Reverse rack 154236-001 1
1-1-12 Washer 145087-001 1
1-1-13 Set screw, SM3.18 149831-101 1
1-1-14 Work clamp plate holder, L 154237-001 1
1-1-15 Washer, plain S3.5 025350-132 1
1-1-16 Screw, SM3.57 100242-003 1
1-1-17 Reverse rod S12637-009 1
1-1-18 Reverse cylinder S12639-001 1
1-1-19 Bolt, socket M3 x 35 S12642-009 2
1-1-20 Joint S12640-009 1
1-1-21 Bolt, socket M3 x 8 018300-836 1
1-1-22 Bolt, socket M3 x 8 018300-836 1
1-1-23 Bolt, M5 x 12 017501-216 1
1-1-24 Nut, 2 M5 021500-216 1
1-1-25 Half union, Q4M5 S18415-101 2
1-2 Outer work clamp, 312 – 1 S12643-001 1
1-3 Screw, flat SM3.18 117291-002 2
1-4 Positioning plate, L 154252-001 1
1-5 Positioning plate, R 154253-001 1
1-6 Screw, pan SM3.57 – 40 x 5 062670-512 4
1-7 Washer, plain L3.5 025350-332 4
1-8 Washer, spring 2 – 3.5 028350-242 4
1-9 Work clamp plate blank, A 154256-101 1
1-10 Feed plate blank, 312 – 1 S12645-001 1
1-11 Inner clamp valve assy, 3 S44745-009 1
1-11-1 Valve setting plate, 4 – 5H S31570-209 1
1-11-2 Air manifold, 3 S44748-001 1
1-11-3 Screw, pan M3 x 25 062302-505 2
1-11-4 Washer, spring 2 – 3 028030-242 2
1-11-5 Washer, plain M3 025030-232 2
1-11-6 Solenoid valve S43683-001 1
1-11-7 Valve harness, x 1 S43696-000 1
1-11-7-1 Valve harness S44746-000 1
1-11-7-2 Valve harness, 24 V S44750-000 1
1-11-8 Half union, Q4M5 S18415-101 2
1-11-9 Regulator assy S45252-000 1
1-11-10 Joint, 3109-4-10 S45254-000 2
1-11-11 Screw, pan M4 x 40 062404-005 2
1-12 Bead band 340400-001 2
1-13 Air tube, 4L = 1300 S03803-000 2
1-14 Air tube, 4L = 300 S28741-000 1
