Brother CS5055PRW Parts Reference List

- 7 -
(2) UPPER SHAFT MECHANISM / NEEDLE BAR / PRESSER FOOT UNIT
No. CODE NAME REMARKS No. CODE NAME REMARKS
UPPER SHAFT MECHANISM 43 XC8765121 SHAFT
1 XE7621001 UPPER SHAFT SUPPLY ASSY CP4 44 XZ5030001 WASHER, SPRING
2 XC3529021 PULLEY 45 048050346 RETAINING RING E5
3 012500532 SET SCREW SOCKET (FT) M5X5 46 XC3338021 SCREW 3X8
4 XC3534121 UPPER SHAFT BEARING PRESSER 47 XC8564031 THREAD TAKE-UP LEVER
5 XC3496021 GIZA TITE 5X16 48 XC4897020 THREAD TAKE-UP LEVER LINK
6 XE5842001 TIMING BELT 420-5KC-6 1000034635 49 XC4898021 PRESSER BAR
7 XC4870021 TENSION PULLEY ASSY 50 XC4899121 PRESSER BAR CLAMP
8 0A4400806 SCREW PAN (S/P WASHER) M4X8 51 XC7207021 SCREW STUD M5
9 XC8739020 TENSION PULLEY HOLDER 52 XC4900021 SPRING
NEEDLE BAR / PRESSER FOOT UNIT 53 XE2555101 PRESSER FOOT HOLDER ASSY
10 XC8741121 BASE HOLDER ASSY 54 132730122 TIGHTENING SCREW 3.57
11 XE8695001 NEEDLE BAR SUPPORTER ASSY 55 XZ5134001 Z FOOT 1000031539
12 XC2420020 SHAFT 56 XC4902021 PRESSER FOOT LIFTER
13 XC8754021 NEEDLE HOLDER SHAFT A 57 048040346 RETAINING RING E4
14 014300532 SET SCREW SOCKET (CP) M3X5 58 XC8766020 THREAD RELEASE LEVER
15 XC8755020 PLATE 59 XC4904121 SPRING
16 060300516 SCREW BIND M3X5 60 146200021 RETAINING RING, CS4
17 X50476021 SPRING 61 XC8767121 BH SWITCH ASSY 1000031597
18 XE3825001 NEEDLE BAR ASSY N 62 0A4400806 SCREW PAN (S/P WASHER) M4X8
19 XE3827001 NEEDLE CLAMP SCREW 63 XC8773020 RUBBER
20 XC2434021 NEEDLE THREAD BLOCK 64 XC8774021 PRESSER SWITCH HOLDER
21 XF5017001 NEEDLE BAR CRANK ROD ASSY 1000032403 65 XC8775021 PF SWITCH ASSY, LE
22 132051022 SCREW, FLAT SM3.57-40X7 L 66 X53169020 BAND
23 012400432 SET SCREW SOCKET (FT) M4X4 67 X53330020 WASHER 1000025734
24 XA1854051 THREADER HOOK ASSEMBLY 68 XE3856001 LEAD WIRE ASSY: GROUND
25 XC2429021 SPRING 69 XC4961021 GIZA TITE 5X20
26 X56851021 LOCK NUT 70 XC4905121 ADJUSTING SCREW
27 014401232 SET SCREW SOCKET (CP) M4X12 71 060302506 SCREW BIND M3X25
28 XC8756021 SHAFT BUSHING 72 XC6056120 PLATE SPRING
29 060300616 SCREW BIND M3X6 73 XC4906020 ADJUSTING PLATE
30 XC8757021 Z PULSE MOTOR: M35SP-9N 74 085411016 TAPTITE BIND B M4X10
31 XC8759021 LEAD WIRE ASSY, ZPM-LE 75 XC4907021 LABEL
32 XC8760020 Z ZIGZAG CAM
33 XC8761121 Z ZIGZAG LEVER ASSY 76 XE6416201 NEEDLE UNIT SUPPLY ASSY CP3 1000031917
34 XC8764020 Z LEVER CAP
35 137713020 POLYESTER SLIDER
36 XC2435020 ZIGZAG ADJUSTING NUT
37 018301032 BOLT SOCKET M3X10
38 048030346 RETAINING RING E3
39 XC2748021 SPRING-Z
40 XC2436021 NEEDLE HOLDER BLOCK
41 XC2437021 SHAFT ASSY
42 XC3037021 SCREW3X10
