Brother CS5055PRW Parts Reference List

- 9 -
(3) FEED UNIT
No. CODE NAME REMARKS No. CODE NAME REMARKS
1 XE6467201 BASE PLATE ASSY 1000033187 45 014400632 SET SCREW SOCKET (CP) M4X6
2 XE5656001 FEED ARM SUPPORTER 46 XE7558001 INNER ROTARY HOOK BRACKET ASSY
3 XE7489001 FEED DOG 47 0A5300806 SCREW PAN (S/P WASHER) M3X8
4 060300616 SCREW BIND M3X6 48 XE7323101 IRH BRACKET SUPPORT PLATE
5 XE2015201 FEED BAR ASSY 49 XC8796021 LOWER SHAFT ASSY
6 137999020 POLYESTER SLIDER 50 XC4943021 TIMING PULLEY D
7 146200021 RETAINING RING, CS4 51 014500532 SET SCREW SOCKET (CP) M5X5
8 XC8789121 HORIZONTAL FEED SHAFT 1000032545 52 X52664020 LOWER SHAFT BUSHING
9 130676121 SET SCREW COLLAR 53 XC3792020 UPPER SHAFT BUSHING
10 X50546020 WASHER,THRUST 54 X51383020 WASHER,THRUST
11 060301206 SCREW BIND M3X12 55 048060346 RETAINING RING E6
12 XC4924021 FEED ARM ASSY 56 XC8798021 SET COLLAR
13 XC4927021 FEED SUPPORTING PLATE 57 XC4944021 BUSHING PRESSER B
14 XC4928120 FEED SUPPORTING PLATE B 58 085310616 TAPTITE BIND B M3X6
15 XC2527121 FEED ADJUSTER 59 XE6468101 NEEDLE PLATE A ASSY 1000028832
16 XC2529020 F GEAR 60 XE6469001 NEEDLE PLATE A
17 XC2530021 SPRING 61 XF2440001 STOPPER PLATE 1000028832
18 137713020 POLYESTER SLIDER 62 XE7164001 NEEDLE PLATE B SUPPORT PLATE
19 XC2531021 SPRING 63 XE6471001 F GEAR STOPPER PLATE
20 XC8791021 FPM HOLDER SUB ASSY 64 XE6472001 NEEDLE PLATE HOLDER 1000029081
21 XC8757021 Z PULSE MOTOR:M35SP-9N 65 060260316 SCREW BIND M2.6X3
22 XC8793021 LEAD WIRE ASSY,FPM-LE 66 XE6473001 SCREW NEEDLE PLATE
23 XC8773020 RUBBER 67 X56655021 RETAINING RING: CSTW-3.5
24 060300416 SCREW BIND M3X4 68 XE1478101 SPRING 1000025521
25 XE6639001 SCREW3X8 69 XC3534121 UPPER SHAFT BEARING PRESSER
26 018402533 BOLT SOCKET M4X25 70 XC3496021 GIZA TITE 5X16
27 XC2537021 SPRING 71 XE7560001 INNER ROTARY HOOK ASSY
28 XC9924021 RETAINING RING 10 72 XC3137000 PILE
29 XC3941021 VERTICAL ADJUSTER SCREW ASSY 73 X52800120 BOBBIN
30 XC2546021 M5 NUT 74 XC3805021 GIZA TITE 5X16
31 XE1940001 SPRING 75 XZ5053001 WASHER EX TOOTH 5
32 XC8794021 VERTICAL FEED SHAFT 76 XE8564001 UNIT WASHER
33 XC2551020 VERTICAL LEVER
34 025040332 WASHER PLAIN L 4 77 XE7622301 FEED UNIT SUPPLY ASSY CP4 1000033506
35 XC8795121 DROP KNOB
36 XC2550021 SPRING
37 048030346 RETAINING RING E3
38 XD0115021 OUTER ROTARY HOOK ASSY
39 XD1943021 OUTER ROTARY HOOK SHAFT
40 137805022 SPACER
41 137976021 WASHER 6
42 XZ5092001 SHAFT SUPPORTER 1000025445
43 0A4400806 SCREW PAN (S/P WASHER) M4X8
44 014400432 SET SCREW SOCKET (CP) M4X4

Brother CS5055PRW Specifications

General

Brand	Brother
Model	CS5055PRW
Category	Sewing Machine
Language	English
