- 11 -

(4) BOBIN WINDING MECHANISM / NEEDLE THREADING MECHANISM

No. CODE NAME REMARKS No. CODE NAME REMARKS

BOBIN WINDING MECHANISM NEEDLE THREADING MECHANISM

1 XE6474001 BOBBIN WINDER ASSY 12 XE7463001 THREAD GUIDE A ASSY

2 048050346 RETAINING RING E5 13 XE6478001 THREAD TENSION HOLDER A ASSY

3 X55238021 RUBBER RING 14 XA0083121 TENSION DISC A

4 XZ5039001 BOBBIN WINDER SHAFT SPRING

15 XA0084121 TENSION DISC B

5 XC8803021 BOBBIN BASE 16 XD0573021 WASHER

6 XE7556001 BOBBIN WINDER SPRING 17 XA1388021 TENSION DISC WASHER

7 XE7557001 BOBBIN WINDER SHAFT STOPPER 18 XC8828020 THREAD RELEASE PLATE

8 XC2612051 SW ASSY:BW-F 19 XE3014001 SPRING

9 XE6076001 SENSER HOLDER 20 XE3015001 THREAD TENSION ADJUSTING SCREW

10 060300516 SCREW BIND M3X5 21 XE3016001 THREAD TENSION PLATE ASSY

11 XC3496021 GIZA TITE 5X16 22 XE3019001 ADJUSTING SCREW SPRING PLATE

23 XE3020101 THREAD TENSION ADJUSTING GEAR

1000033516

24 XE5650001 THREAD TENSION DIAL

25 XC9234021 TENSION DIAL SHAFT

26 XE1924101 NOTCHED SPRING

27 062300416 SCREW PAN M3X4

28 060300416 SCREW BIND M3X4

29 XE6480001 THREAD GUIDE B ASSY

30 XE6481001 THREAD TAKE-UP HOLDER B

31 XC6957121 THREAD TAKE UP SPRING

32 XC2648121 THREAD CATCHING SPRING CASE

33 0A4301806 SCREW, PAN (S/P WASHE) M3X18

34 XE5984001 SPRING TAPE

35 XE6483001 THREAD GUIDE WIRE

36 085411416 TAPTITE BIND B M4X14

37 060400616 SCREW BIND M4X6
