Brother CS5055PRW Parts Reference List

- 13 -
(5) ELECTRIC PARTS / MAIN MOTOR UNIT
No. CODE NAME REMARKS No. CODE NAME REMARKS
ELECTRIC PARTS MAIN MOTOR UNIT
1 XE8622001 MAIN PCB SUPPLY ASSY-50 18 XE5843001 TIMING BELT 2M-372-6 1000034635
(F0G******~) 19 XE7610101 MAIN MOTOR SUPPLY ASSY CP4 1000031760
XF0336001 MAIN PCB SUPPLY ASSY 1000024596 20 XC3803120 MOTOR FAN 1000033777
(CE8080PRW, CE8080) 21 XC8815121 MOTOR HOLDER 1000031760
XF4937001 MAIN PCB SUPPLY ASSY 1000032194 22 0A5300806 SCREW PAN (S/P WASHER) M3X8
(CE7070PRW) 23 XC3805021 GIZA TITE 5X16
2 XC9830021 FC JACK SUPPLY ASSY-120 24 XZ5053001 WASHER EX TOOTH 5
XC9832021 FC JACK SUPPLY ASSY-230 1000024361 25 XZ5096001 WASHER 1000027367
3 XC8809121 SHUTTER COVER 26 XC8816071 FOOT CONTROLLER:FC-322-81-LF 1000035004
4 085311016 TAPTITE BIND B M3X10 27 X53169020 BAND 1000032997
5 087411416 TAPTITE CUP B M4X14
6 XE7613001 POWER PCB SUPPLY ASSY CP4 120V 28 XE8641001 MAIN PCB SUPPLY SET-50
XE8831001 POWER PCB SUPPLY ASSY CP4 230V 1000024361 (~E0G******)
7 XC8824021 LEAD WIRE ASSY,POWER-LE
8 XE6484001 INSULATION COVER
9 XE6485001 INSULATION PLATE
10 XE7107001 POWER PLATE SPRING 1000032545
11 XE3728001 SPRING 1000032545
10 XF5483101 LEAD WIRE ASSY: GROUND LL 1000034625
11 060300616 SCREW BIND M3X6 1000033506
12 XE7309001 INLET ASSY CP4 120
XE8609001 INLET ASSY CP4 230 1000024361
13 087411416 TAPTITE CUP B M4X14
14 060400816 SCREW BIND M4X8
15 085311016 TAPTITE BIND B M3X10
16 XC6052021 POWER SUPPLY CORD:UL CSA-LF
XF0749101 POWER SUPPLY CORD:BRZ (BRA120V) 1000029467
XE4301101 POWER SUPPLY CORD:BRZ 220V 1000029467
(BRA220V)
XD0111151 POWER SUPPLY CORD:IRAM (ARG) 1000028780
XA0070121 POWER SUPPLY CORD (OTHER) 1000024361
17 XE7555001 INLET PRESSER
