Brother CS5055PRW Parts Reference List

- 3 -
(1) MAIN FRAME / COVER
No. CODE NAME REMARKS No. CODE NAME REMARKS
1 XE6631001 BOBBIN WINDER GUIDE ASSY XE7562001 DECORATION PLATE B
2 0A5300806 SCREW PAN (S/P WASHER) M3X8 (CE5500PRW, CS5055PRW)
3 XE6425101 SPOOL PIN 1000031891 XF0207001 DECORATION PLATE B 1000024596
3 XF4744001 SPOOL PIN ASSY 1000031891 (CE8080PRW, CE8080)
4 XE6427001 SPOOL PIN HOLDER XF4949001 DECORATION PLATE B (CE7070PRW) 1000032194
5 XE7218001 SPOOL PIN SUPPORTER 1000031891 31 XE8562001 DECORATION COVER (CE8080, CE7070PRW) 1000025628
6 XE6633001 SPOOL PIN STOP PLATE XE6441001 DECORATION COVER (OTHER)
7 XE7626001 SPOOL PIN SPRING COVER 1000031891 32 085411416 TAPTITE BIND B M4X14
8 XE7695001 SPOOL PIN SPRING 33 XE6444001 REVERSE BUTTON
9 087411416 TAPTITE CUP B M4X14 34 XE6449001 SELECTING BUTTON A
10 XE8912001 BOBBIN PRESSER 35 XE6450001 SELECTING BUTTON B
11 0A4302006 SCREW PAN (S/P WASHER) M3X20 36 XE6451001 MANUAL BUTTON A
12 021300106 NUT 1 M3 37 XE6452001 MANUAL BUTTON B
13 XE6429001 THREAD GUIDE PLATE ASSY 38 XE0849001 FRONT COVER THREAD GUARD
14 XE6634001 THREAD GUIDE SUPPORTING PLATE 39 XC4077021 BASE PLATE RUBBER
15 XE7286001 CUTTER COVER ASSY 40 XC9822021 LCD SUPPLY ASSY
16 XE6640001 CUTTER COVER 41 XE6514001 LCD HOLDER
17 XE6641001 CUTTER HOLDER PLATE 42 XE7639001 OPERATION PCB SUPPLY ASSY V61
18 X80321021 NT LOWER THREAD CUTTER (CE5500, CE5500PRW, CS5055PRW,
19 060300416 SCREW BIND M3X4 CE5500T, CE7070PRW)
20 085411016 TAPTITE BIND B M4X10 XF0177001 OPERATION PCB SUPPLY ASSY 1000024596
21 138337022 RUBBER CUSHION A (CE8080PRW, CE8080)
22 026350235 WASHER PLAIN M 3.5 43 XE7606101 SSVR PCB SUPPLY ASSY CP4L
23 083361216 TAPTITE PAN B M3.5X12 44 XE9784001 LED LAMP SUPPLY ASSY CP4S 1000025446
24 XC4077021 BASE PLATE RUBBER 45 085311016 TAPTITE BIND B M3X10
25 XE1372001 SPOOL PRESSER C 46 X53169020 BAND
26 XE8361001 BELT STOPPER PLATE 47 XZ5049001 GIZA TITE (S/P W) 5X18
27 085411416 TAPTITE BIND B M4X14 48 XE2261001 GIZA TITE (S/P W) 4X25
28 XZ5120121 FRONT COVER (CE5500PRW) 1000031390 49 XC3588021 GIZA TITE 4X12
XZ5124121 FRONT COVER (CE8080PRW) 1000031390 50 XC7566051 SCREW, PAN(S/P WASHER) M4X8
XZ5123121 FRONT COVER (CS5055PRW) 1000031390 51 XE6454001 FACE PLATE
XZ5125121 FRONT COVER (CE8080) 1000031390 52 XA3337022 TAPTITE,CUP P M4X20
XZ5121121 FRONT COVER (CE5500: ARG, PRY) 1000031390 53 XE6455001 ACCESSORY TABLE
XE8371001 FRONT COVER (CE5500: OTHER) 54 XE6456001 NEEDLE PLATE B ASSY
XF3846001 FRONT COVER (CE5500T) 1000029814 55 XE6457001 NEEDLE PLATE B
XF4947001 FRONT COVER (CE7070PRW) 1000032194 56 XC7371022 SLIDE BUTTON
29 XE7291001 DECORATION PLATE A 57 XD1666052 CUTTER COVER
(CE5500, CE5500PRW, CS5055PRW, 58 XC2368121 SPRING PLATE 1000031909
CE5500T) 59 X80321021 NT LOWER THREAD CUTTER
XF0205001 DECORATION PLATE A 1000024596 60 XD1645021 NEEDLE PLATE COVER SUPPLY ASSY
(CE8080PRW) 61 XE7163001 SLIDE BUTTON B
XF0652001 DECORATION PLATE A (CE8080) 1000025628 62 XE6459001 BASE COVER
XF4948001 DECORATION PLATE A (CE7070PRW) 1000032194 63 085411016 TAPTITE BIND B M4X10
30 XE8372001 DECORATION PLATE B (CE5500, CE5500T) 64 XE3360001 LOWER THREAD GUIDE LABEL
