1.3.27 Display machine log information (Function code 80)
<Function>
This function is used to display the log information on the LCD.
<Operating Procedure>
(1) Press the [8], and then the [0] in the initial state of maintenance mode. For models
without keypad, press the [▲] or [▼] to display “MAINTENANCE 80” on the LCD and
press the [OK]. “MACERR_01:****” is displayed on the LCD (**** indicates error code).
(2) Press the [Start] or [Mono Start], then the next item is displayed. Press the [▲] to go
back to the previous item.
(3) Press the [X] or [Stop], and the machine returns to the initial state of maintenance mode.
 Maintenance information
LCD Description
MACERR_##:0000 Machine error log (last ten errors)
*1
USB:000G8J000166 Serial number
*2
MAC:008077112233 MAC address
PCB:911309123456 Main PCB serial number
KTN_ERM:87% Amount of remaining toner estimated from coverage
KTN_RRM:67% Amount of remaining toner estimated from the number of develop
rotations
DRUM_PG:00000000 Printed pages for drum unit
PFMP_PG:00000000 Pages fed from PF kit MP (MP models only)
PFK1_PG:00000000 Pages fed from PF kit 1
FUSR_PG:00000000 Printed pages on fuser unit
LASR_PG:00000000 Printed pages on laser unit
TTL_PG:00000000 Total number of pages printed
DX_PG:00000000 Paper input for duplex tray
TTLCOPY:00000000 Total pages copied
DX_COPY:00000000 Total pages copied on both sides
TTLPCPT:00000000 Total number of pages printed via PC
DX_PCPT:00000000 Total number of two-sided pages printed via PC
TTLFAX:00000000 Total List / Fax pages printed (For models with FAX only)
DX_FAX:00000000
Total List / Fax pages printed on both sides (For models with FAX only)
TTL_OTH:00000000 Total number of pages printed by other methods
DX_OTH:00000000 Total number of two-sided pages printed by other methods
KCVRGUSI:4.32%* Average coverage by the current toner cartridge
KCVRGACC:3.47% Accumulated average coverage of toner cartridge
DRUM:00000000 Number of drum rotations
KTN_RND: 00000000 Number of develop roller rotations
TNSPL:0000000000 Supply amount of the toner box (Toner box models only)
MP_PG:00000000 Paper input for MP tray (MP models only)
MN_PG:00000000 Paper input for manual feed slot (Manual feed slot models only)
TR1_PG:00000000 Paper input for paper tray
DX_PG:00000000 Paper passed through duplex tray
A4+LTR:00000000 Total paper input for A4 and Letter
LG+FOL:00000000 Total paper input for Legal and Folio

Brother DCP-B7535DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Direct printing	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Client and Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan)
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Client and Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, Web Services (Print/Scan)
Internal memory	128 MB
Card reader integrated	No
Sound pressure level (copying)	49 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	36 cpm
Scan to	E-mail, FTP, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Input color depth	30 bit
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, XPS
Optical scanning resolution	1200 x 1200 DPI
Printer fonts	PCL, PostScript
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PDF 1.7, PostScript 3
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	215 x 355 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 230 g/m²
Display	LCD
Control type	Buttons
Product color	Gray
Market positioning	Home & office
AC input voltage	110 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	43.5 W
Power consumption (standby)	0.8 W
Power consumption (average operating)	450 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	318.5 mm
Weight	11800 g
