Brother DCP-L2550DN User Manual

5-8
Confidential
1.3.5 Set worker switches (WSW) and print worker switch setting data
(Function code 10, 11)
[1] Set worker switches (Function code 10)
<Function>
The worker switches shown in the table below can be used to set the function to satisfy various
requirements. These switch settings can be changed using the keys on the control panel.
The worker switches are factory set to conform to the laws and regulations of the country the
machine is shipped to. Do not change these settings unless necessary.
WSW No. Function WSW No. Function
WSW01 Dial pulse setting WSW38 V.34 transmission settings
WSW02 Tone signal setting WSW39 V.34 transmission speed
WSW03 PABX mode setting WSW40 V.34 modem settings
WSW04 Transfer facility setting WSW41 ON-duration of the scanning light
source
WSW05 1st dial tone and busy tone
detection WSW42 Internet mail settings
WSW06 [Redial/Pause] and 2nd dial tone
detection
WSW43 Function setting 16
WSW44 Speeding up scanning-1
WSW07 Dial tone setting 1 WSW45 Speeding up scanning-2
WSW08 Dial tone setting 2 WSW46 PC power monitoring and
parallel port settings
WSW09 Protocol definition 1
WSW10 Protocol definition 2 WSW47 Switching between high- and full-
speed USB
WSW11 Busy tone setting
WSW12 Signal detection condition setting WSW48 USB setup latency
WSW13 Modem setting WSW49 End-of-copying beep
WSW14 AUTO ANS facility setting WSW50 SDAA setting
WSW15 Redial facility setting WSW51 Function setting 17
WSW16 Function setting 1 WSW52 Function setting 18
WSW17 Function setting 2 WSW53 Function setting 19
WSW18 Function setting 3 WSW54 Function setting 20
WSW19 Transmission speed setting WSW55 Interval for regular developing
bias value correction
WSW20 Overseas communication mode
setting WSW56 Function setting 21
WSW21 TAD setting 1 WSW57 Function setting 22
WSW22 ECM and call waiting caller ID WSW58 Function setting 23
WSW23 Communication setting WSW59 Function setting 24
WSW24 TAD setting 2 WSW60 Function setting 25
WSW25 TAD setting 3 WSW61 Scanning light intensity to judge
to be stable 1
WSW26 Function setting 4
WSW27 Function setting 5 WSW62 Scanning light intensity to judge
to be stable 2
WSW28 Function setting 6
WSW29 Function setting 7 WSW63 Function setting 26
WSW30 Function setting 8 WSW64 Language / default paper size
setting
WSW31 Function setting 9
WSW32 Function setting 10 WSW65 Paper support setting
WSW33 Function setting 11 WSW66
Change of the setting is prohibited
WSW34 Function setting 12 WSW67 Change of the setting is prohibited
WSW35 Function setting 13 WSW68 Change of the setting is prohibited
WSW36 Function setting 14 WSW69 Change of the setting is prohibited
WSW37 Function setting 15 WSW70 Change of the setting is prohibited

Brother DCP-L2550DN Specifications

General

N-up printing	2, 4, 6, 9, 16, 25
Barcode printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	34 cpm
Scan to	E-mail, FTP, File, Image, OCR
Scan drivers	SANE, TWAIN
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	15000 pages per month
Recommended duty cycle	0 - 2000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Cabling technology	10/100Base-T(X)
Security algorithms	APOP, SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS , DNS Resolver, mDNS , LLMNR, LPR/LPD, Custom Raw Port/Port9100, client SMTP Client, IPP/IPPS, server FTP, SNMPv1/v2c/v3, server HTTP/HTTPS, client/server TFTP, ICMP, client SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, risponditore LLMNR, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, client SMTP, server FTP, SNMPv1/v2c/v3, server HTTP/ HTTPS, client/server TFTP, ICMPv6, client SNTP
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Standard interfaces	Ethernet, USB 2.0
Sound power level (standby)	30 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
Power consumption (off)	0.03 W
Power consumption (sleep)	0.6 W
Power consumption (standby)	6.2 W
Power consumption (printing)	440 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	1.348 kWh/week
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Package depth	517 mm
Package width	580 mm
Package height	434 mm
Package weight	14400 g
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 230 g/m²
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016, Windows Server 2016 x64
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	318.5 mm
